5. AFH04639 High Pressure Fuel Pipes Plate A

Каталог запасных частей к технике: Perkins 1106D. AFH04639 High Pressure Fuel Pipes Plate A

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано BAW Caterpillar Cummins DCEC DongFeng Doosan FAW Great Wall Hitachi HOWO HSW IVECO Komatsu LGMG Perkins Raywin SDEC Shaanxi Valmet Weichai XINCHAI YTO Yuchai ZF Алтайдизель Барнаултрансмаш ВТЗ ГАЗ ЗиД ЗМЗ Камский автозавод ММЗ СМД ТМЗ УМЗ ЧТЗ ЮМЗ ЯЗДА ЯМЗ

Модель Не выбрано 1006-6T (2010) 1106D (2012)

Схема > Не выбрано ACE39876 Short Engine Plate A ACHP0010 Cylinder Block and Liners Plate A ACHP0010 Rear End Oil Seal Plate A HBH03158 Cylinder Head Cover Plate A HBH03158 Cylinder Head Cover (From Engine Number U000881N, Upto Engine Number U003602P) Plate C HBH03158 Cylinder Head Cover (From Engine Number U003603P) Plate F HBH03158 Cylinder Head Cover Base (Upto Engine Number U000880N) Plate b HBH03158 Cylinder Head Cover Base (From Engine NumberU000881N, Upto Engine Number U001906P) Plate D HBH03158 Cylinder Head Cover Base (From Engine Number U001907P) Plate E KBH00709 Front End Drive Input (Upto Engine Number U030232V) Plate A KBH00709 Front End Drive Input (From Engine Number U030233V) Plate B QCH00049 Timing Case Plate A QCH00049 Timing Case Plate B QCH00049 Timing Cover Plate A XBH00469 Engine Lifting Eyes Plate A ACHP0010 Crankshaft, Main and Big End Bearings (Upto Engine Number U030232V) Plate A ACHP0010 Crankshaft, Main and Big End Bearings (From Engine Number U030233V) Plate B ACHP0010 Crankshaft, Main and Big End Bearings Plate B ACHP0010 Pistons and Rings Plate A ACHP0010 Connecting Rods (Upto Engine Number U023763U) Plate A АСНР0010 Connecting Rods (From Engine Number U023764U) Plate A ACHP0010 Cylinder Head Assembly (Upto Engine Number U001906P) Plate A ACHP0010 Cylinder Head Assembly (From Engine Number U001907P) Plate B ACHP0010 Rocker Shaft Assembly Plate A ACHP0010 Timing Gear and Camshaft Plate A AFH04639 High Pressure Fuel Pump Plate A AFH04639 Fuel Rail (Upto Engine Number U022142T) Plate A AFH04639 Fuel Rail (From Engine Number U022143T) Plate A AFH04639 Atomisers Plate A AFH04639 High Pressure Fuel Pipes Plate A AFH04639 Pipework Plate A VBH02553 Low Pressure Fuel Pipes Plate A VBH02553 Low Pressure Fuel Pipes Plate B VBH02553 Fuel Leak-Off Pipe Plate A VBH02553 Fuel Leak-Off Pipe Plate B VBH02553 Fuel Filter Plate A VDH00015 Fuel Filter (Upto Engine Number U004628P) Plate A VDH00015 Fuel Filter (From Engine Number U004629P) Plate A ZVH01037 Fuel Pre-Lift Pump Plate B ZVH01037 Water Trap (Upto Engine Number U010829S) Plate A ZVH01037 Water Trap (From Engine Number U010830S) Plate B AFH04639 Engine Control Module (Upto Engine Number U021093T) Plate A AFH04639 Engine Control Module (From Engine Number U021094T) Plate A AFH04639 Engine Control Module Plate B AFH04639 Engine Control Module Plate C AFH04639 Sensors Plate A AFH04639 Sensors Plate B AFH04639 Sensors Plate C CDH01077 Flywheel Housing Plate A DDH02053 Flywheel and Starter Ring Plate A EDH00939 Starter Motor Plate A GBH02855 Sump Plate A GBH02855 Dipstick and Filler Tube Plate A GBH02855 Oil Strainer Plate A HBH03158 Breather (Upto Engine Number U003602P) Plate A НВН03158 Breather (From Engine Number U003603P) Plate B HDH00002 Filler Plate A JBH02569 Oil Cooler Plate A JBH02569 Oil Filter Plate A RBH00032 Lubricating Oil Pump and Delivery Housing Plate A ZJH00544 Lubricating Oil Pressure Switch/Gauge Plate A ZJH00544 Lubricating Oil Pressure Switch/Gauge Plate B FBH01079 Fan Drive Plate A LBH02281 Water Pump (Upto Engine Number U023762U) Plate A LBH02281 Water Pump (From Engine Number U023763U) Plate B LBH02281 Pipes Plate A LDH00712 Water Outlet Housing Plate A MDH01457 Fan Plate A ZMH01391 Radiator and Cowling Plate A ZMH01391 Radiator Bracket and Fixings (Upto Engine Number U004996P) Plate A ZMH01391 Radiator Bracket and Fixings (From Engine Number U004997P) Plate A ZMH01391 Radiator Bracket and Fixings Plate B ZMH01391 Radiator and Hoses Plate A ZMH01391 Radiator and Hoses Plate B NDH02830 Alternator Plate A NDH02830 Pulleys Plate A NDH02830 Alternator Bracket and Fixings Plate A HBH03158 Blanking Plates (Upto Engine Number U0089634) Plate A HDH00002 Blanking Plates Plate A HDH00002 Blanking Plates Plate B JDH00038 Oil Filter Plate A JBH02569 Blanking Plates Plate A QDH01415 Blanking Plugs Plate A ZCH01201 Engine Mounts Plate A SBH01678 Turbocharger Plate A SBH01678 Feed Pipes Plate A SBH01678 Leak-Off Pipes Plate A SBH01678 Wastegate Sensor Plate A SBH01678 Pipework and Connections Plate A SBH01678 Air Filters Plate A SBH01678 Air Filters Plate B TBH00939 Induction Manifold Plate A TBH00939 Pipework and Connections Plate A WDH00372 Heater Plugs Plate A SBH01678 Exhaust Manifold Plate A SDH00420 Exhaust Outlet Plate A ZNH00267 Wiring Looms Plate A ZNH00267 Wiring Loom Service Connectors Plate A ZMH01391 Guards Plate A ZMH01391 Guards Plate B VBH02553 Miscellaneous Plate A ZZH01054 Miscellaneous and Auxiliaries Plate A

1

2

3

4

5

6

7

8

9

Позиция на иллюстрации	Заводской номер детали		Название детали
1	3525A201		Pipe - fuel inj no 1 cyl
2	3525A202		Pipe - fuel inj no 2 cyl
3	3525A203		Pipe - fuel inj no 3 cyl
4	3525A204		Pipe - fuel inj no 4 cyl
5	3525A205		Pipe - fuel inj no 5 cyl
6	3525A206		Pipe - fuel inj no 6 cyl
7	2646E203		Clip
8	2646E203		Clip
9	U5MK1124		Protection kit

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
