Каталог запасных частей к технике: FAW CA 4DC2-10E4. Cylinder head and drain cock assy
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 1002028AX2 | Nut | |
| 2 | 1002061A26E | Gear chamber cover | |
| 3 | CQ1200616 | Double head stud | |
| 4 | 1002065AX2 | Plat cover-gear chamber cover | |
| 5 | 1002069-C012 | Gasket | |
| 6 | 1002073-X2 | Square sealing ring | |
| 7 | 1002074-X2 | Pentagram sealing ring | |
| 8 | 1002076-X2 | Water inlet sealing ring | |
| 9 | CQ1480820A | Combination bolt | |
| 10 | CQ1480840B | Combination bolt | |
| 11 | CQ1480845B | Combination bolt | |
| 12 | CQ1480850B | Combination bolt | |
| 13 | 1002027AX2 | Double head stud | |
| 14 | Q5220815 | Circular pin | |
| 15 | 1002086-C012 | Fitting pin | |
| 16 | 1002084-C012 | Bolt for the compressor | |
| 17 | 1002083-55D | Bolt for the pump | |
| 18 | 1002088-55D | Flange | |
| 19 | S1002080A55D | Gear chamber space | |
| 20 | 1002087-55D | Bolt | |
| 21 | CQ1461085 | Combination bolt | |
| 22 | CQ1461090 | Combination bolt | |
| 23 | CQ1480855B | Combination bolt | |
| 24 | CQ1480860B | Combination bolt | |
| 25 | CQ1480816A | Combination bolt | |
| 26 | CQ1481070B | Combination bolt | |
| 27 | 1002082AX2 | Space gasket | |
| 28 | 1005041-X2 | Timing needle | |
| 29 | 1005090AX2A1 | Front oil sea | |
| 30 | 1002010-26E | Cylinder block | |
| 31 | 1002017-X2 | Blockage | |
| 32 | 1002019-X2 | Bowl type plut | |
| 33 | 1002031-D1 | Bowl type plut | |
| 34 | 1003027AX2 | Bowl type plut | |
| 35 | CQ72222 | Чашкообразная заставленная пластинка | |
| 36 | Q5210510 | Circular pin | |
| 37 | Q5220614 | Circular pin | |
| 38 | Q5221020 | Circular pin | |
| 39 | Q5221026 | Circular pin | |
| 40 | Q5280812 | Spring circular pin | |
| 41 | Q61901 | Коническая пробка | |
| 42 | 1002031-X2 | Bowl type plut | |
| 43 | 1002013-X2 | Bowl type plut | |
| 44 | B1305010AS001 | Drain cock assy | |
| 45 | 1002026-X2A1 | Cylinder liner | |
| 46 | Q61903 | Коническая пробка |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
