Каталог запасных частей к технике: DCEC 6ZTAA13-G2. PP43715 Performance parts

Тип техники

Марка

Модель

Схема

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

Позиция на иллюстрации	Заводской номер детали		Название детали
1	4999933		PISTON, ENGINE
2	C2830730		SCREW, HEX FLANGE HEAD CA
3	C2869962		NOZZLE, PISTON COOLING
4	C2874196		HEAD, CYLINDER TLA
5	4003966		SEAL, VALVE STEM
6	3680883		COLLET, VALVE
7	C2874198		HEAD, CYLINDER
8	C3935271		SCREW, HEX FLANGE HEAD CA
9	C3963990		WASHER, SEALING
10	C3102095		GUIDE, VALVE SPRING
11	C4960050		SPRING, VALVE
12	C4960108		VALVE, INTAKE
13	C4975322		RETAINER, VALVE SPRING
14	C4999807		VALVE, EXHAUST
15	C2874332		ROD, ENGINE CONNECTING
16	C3009953		KEY, PLAIN WOODRUFF
17	C3093806		SCREW, HEX FLANGE HEAD CA
18	C3101459		SCREW, TWELVE POINT CAP
19	C3102136		SCREW, BANJO CONNECTOR
20	C3820782		RING, RETAINING
21	C4959944		PLATE, CLAMPING
22	C4959945		GEAR, CAMSHAFT
23	C4959949		RING, COMPRESSION PISTON
24	C4974953		RING, OIL PISTON
25	C4974970		CLAMP, INJECTOR
26	C4974971		CLAMP, INJECTOR
27	C4974985		RING, COMPRESSION PISTON
28	C4975036		PIN, PISTON
29	C4975249		GASKET, CYLINDER HEAD
30	C4975321		SCREW, HEX FLANGE HEAD CA
31	C4999792		CAMSHAFT
32	C4999948		BEARING, CONNECTING ROD
33	C4999949		BEARING, CONNECTING ROD
34	C2874505		INJECTOR

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
