Каталог запасных частей к технике: DCEC 6CTA8.3-C190-II. PP40722 Performance Parts

Тип техники

Марка

Модель

Схема

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

33

34

35

36

Позиция на иллюстрации	Заводской номер детали		Название детали
1	C3008464		PLUG, PIPE
2	C3008468		PLUG, PIPE
3	C3069809		SCREW, HEX FLANGE HEAD CA
4	C3415430		GEAR, CAMSHAFT
5	C3415501		GASKET, CYLINDER HEAD
6	C3900227		SCREW, HEXAGON HEAD CAP
7	C3901383		ROD, ENGINE CONNECTING
8	C3902332		KEY, PLAIN WOODRUFF
9	C3909886		SEAL, INJECTOR
10	C3910279		CLAMP, INJECTOR
11	C3917729		SCREW, HEX FLANGE HEAD CA
12	C3919918		RING, COMPRESSION PISTON
13	C3920692		RING, RETAINING
14	C3921919		RING, OIL PISTON
15	C3922686		RING, COMPRESSION PISTON
16	C3923478		CAMSHAFT
17	C3923537		PISTON, ENGINE
18	C3927155		SUPPORT, CAMSHAFT THRUST
19	C3934046		PIN, PISTON
20	C3939346		HEAD, CYLINDER
21	3901177		COLLET, VALVE
22	C3972757		RETAINER, VALVE SPRING
23	C3921444		VALVE, EXHAUST
24	C3924492		VALVE, INTAKE
25	C3927642		SEAL, VALVE STEM
26	C3973493		HEAD, CYLINDER
27	3908830		INSERT, VALVE
28	3925863		GUIDE, VALVE STEM
29	3970278		INSERT, VALVE
30	C3914035		PLUG, EXPANSION
31	C3920443		PLUG, EXPANSION
32	C3922072		PLUG, EXPANSION
33	C3991085		SPRING, VALVE
34	C3950661		BEARING, CONNECTING ROD
35	C3960043		SCREW, HEX FLANGE HEAD CA
36	C4948364		INJECTOR

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
