Каталог запасных частей к технике: Neoplan N 516 SHD (MB) E3. TOILET
/250.gif)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34.2
35
36
37
38
39
40
41
42
43
44
45
46
46.1
47
47.1
48
48.1
49
49.1
50
50.1
51
52
53
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 11039776 | 11039776 | LAVATORY | |
| 11039777 | 11039777 | LAVATORY | |
| 11039785 | 11039785 | LAVATORY | |
| 11039779 | 11039779 | LAVATORY | |
| 11039790 | 11039790 | LAVATORY | |
| 11039789 | 11039789 | LAVATORY | |
| 11039852 | 11039852 | LAVATORY | |
| 11039855 | 11039855 | LAVATORY | |
| 11039851 | 11039851 | LAVATORY | |
| 11068426 | 11068426 | LAVATORY | |
| 1 | 11068423 | LAVATORY | |
| 2 | 11039868 | LAVATORY BRUSH | |
| 3 | BOW | BOW | |
| 4 | 11039857 | WASHING TABLE | |
| 5 | ADHESIONCHAMP | ADHESION CHAMP 20mm | |
| 6 | WATERPRESSUREHOSE | WATER PRESSURE HOSE | |
| 7 | 11039865 | PRESSURE TIP SWITCH | |
| 8 | PRESSURETIPSWITCH | PRESSURE TIP SWITCH | |
| 9 | 11039883 | SCREWING | |
| 10 | WATERDRAINTANK | WATER DRAIN TANK W. COVER | |
| 11 | 11039881 | TANK PASSAGE | |
| 12 | PLASTICHOSE | PLASTIC HOSE | |
| 13 | HOSECLAMP | HOSE CLAMP | |
| 14 | HOSECLAMP | HOSE CLAMP | |
| 15 | 11040216 | BOWLS 280/380 WHITE | |
| 15 | 11040217 | SINK STAINLESS STEEL | |
| 15 | 11040218 | SINKS 450 Q K 121 ARCTIC WHITE | |
| 15 | 11040219 | BASIN 280x380 DEPTH 145MM | |
| 16 | 11039882 | PLUG VALVE | |
| 17 | 11039864 | OUTLET COCK | |
| 18 | 11039876 | WASHING TABLE | |
| 19 | 11039858 | WASTEBOX COVER | |
| 20 | 11039862 | REFUSE CONTAINER | |
| 21 | MIRROR | MIRROR | |
| 22 | SWINGHINGE | SWING HINGE | |
| 23 | HINGESSPIEGELO | HINGES SPIEGELO-BERKANTE | |
| 24 | LIGHTING | LIGHTING | |
| 25 | 11040221 | TOWEL RESERVOIR | |
| 26 | 11040222 | SOAP RESERVOIR | |
| 27 | SHELFBOARD | SHELF BOARD SIDE MIRROR CABINET | |
| 28 | INTERIORCEILING | INTERIOR CEILING MIRROR CABINET | |
| 29 | 11039927 | TOILET SLIDER | |
| 30 | BOLTPLATE | BOLT PLATE | |
| 31 | 11039879 | TECHNICBOX | |
| 32 | FASTENINGBRACKET | FASTENING BRACKET | |
| 33 | BOLTPLATE | BOLT PLATE | |
| 34 | BOTTOMPARTS | BEDNORZ- BOTTOM PARTS | |
| 34.1 | BEDNORZBOLT | BEDNORZ BOLT | |
| 34.2 | RING | RING | |
| 35 | PVCFOAMPLASTIC | PVC- FOAM PLASTIC TAPE GREY | |
| 36 | PVCFOAMPLASTIC | PVC- FOAM PLASTIC TAPE GREY | |
| 37 | HOSECLAMP | HOSE CLAMP | |
| 38 | VENTILATIONHOSE | VENTILATION HOSE | |
| 39 | 11039877 | COVERING | |
| 40 | 11039867 | LAVATORY SEAT | |
| 41 | 11039878 | CEESPIT TANK | |
| 42 | SOUNDWALL | SOUND WALL | |
| 43 | LININGSTRIP | ANTI SLIPPING LINING STRIP | |
| 44 | ABFLUBDECKELCALYPSO | ABFLUBDECKEL CALYPSO | |
| 45 | TUR | TUR | |
| 46 | TURSCHLOBWHITE | TURSCHLOB WHITE | |
| 46.1 | TURSCHLOBBLACK | TURSCHLOB BLACK | |
| 47 | TURVERRIEGELUNGINTERIORWHITE | TURVERRIEGELUNG INTERIOR WHITE | |
| 47.1 | TURVERRIEGELUNGBLACKINTERIOR | TURVERRIEGELUNG BLACK INTERIOR | |
| 48 | doorhandle | WHITE door handle | |
| 48.1 | BLACKdoorhandle | BLACK door handle | |
| 49 | doorknobWHITE | door knob WHITE | |
| 49.1 | doorknobBLACK | door knob BLACK | |
| 50 | 11040220 | HANDLE WITH WHITE HEWI ROSETTE | |
| 50.1 | HANDLEROSETTE | HEWI WITH BLACK HANDLE ROSETTE | |
| 51 | 11040223 | WALL HOOK 30MM WHITE HEWI OUTREACH | |
| 52 | HALOGENSPOT | HALOGEN SPOT | |
| 53 | LAMP | LAMP | |
| 11039890 | 11039890 | KPL PNEUMATIC SOLENOID BLOCK | |
| 11039896 | 11039896 | PROCESS CONTROL | |
| 11039897 | 11039897 | FLOAT SWITCH FOR WC - TECHNOLOGY | |
| 11039898 | 11039898 | LEVEL COMPENSATION-SPUMPE | |
| 11039899 | 11039899 | FLOAT SWITCH FOR "CC" | |
| 11039905 | 11039905 | FLUSHING PUMP UNIT FOR CC | |
| 11039907 | 11039907 | Nozzle WC TOILET | |
| 11039908 | 11039908 | TIME RELAY FOR HAND WASHING PUMP CC - MO DUL | |
| 11039910 | 11039910 | SEAL FOR DRAIN VALVE | |
| 11039913 | 11039913 | END TYPE 840 | |
| 11039914 | 11039914 | INPUT DRIVE TYPE 840 | |
| 11039915 | 11039915 | IMPELLER PUMP FOR JABSCO | |
| 11039916 | 11039916 | TIME MEMBER FOR CC-MO DULTOILETTE | |
| 11039919 | 11039919 | IMPELLER FOR FLUSHING PUMP | |
| 11039923 | 11039923 | FLOW CONTROL VALVE FOR TOILET VALVE 2002.089.37 | |
| 11039924 | 11039924 | RING PIECE HOLLOW BOLT FOR TOILET-TENSCHIEBER 2002.089.37 | |
| 11039928 | 11039928 | TOILET VALVE WITH PRESSURE - | |
| 11040057 | 11040057 | CONTROL BOARD F. TOILET CC | |
| 11057426 | 11057426 | WATER STOP VALVE FOR TOILET | |
| 11060606 | 11060606 | WATER STOP FOR WC | |
| 11061292 | 11061292 | RINSE VALVE | |
| 14000192 | 14000192 | ADAPTER BOARD | |
| 14002271 | 14002271 | WATER FILTER JABSCO MODEL 36400 - 0000 | |
| 14003652 | 14003652 | FLUSHING SYSTEM CC | |
| 14006031 | 14006031 | AIR CYLINDER DOUBLE ACTING | |
| 14010570 | 14010570 | TOILET BOWL CHEMISTRY | |
| 14010727 | 14010727 | SEAL PLATE WITH EDGE | |
| 14010864 | 14010864 | TOILET KEY TYPE CC |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
