1
2
3
4
5
7
8
9
10
11
11
12
13
14
15
16
17
18
19
Позиция на иллюстрации
Заводской номер детали
Название детали
1822.077.10
1822.077.10
НYDRОNIС 30
1
PUMP
PUMP 24V
2
ELECTRICMOTOR
ELECTRIC MOTOR 24V
3
COUPLING
COUPLING
4
IGNITIONSPARKGENERATOR
IGNITION SPARK GENERATOR 24V
5
IGNITIONELECTRODE
IGNITION ELECTRODE
7
FUELATOMIZERNOZZLE
FUEL ATOMIZER NOZZLE
8
TWINLEAF-SPRINGCONTACT
TWIN LEAF-SPRING CONTACT
9
FUSE
FUSE
10
CONTROLLUNIT
CONTROLL UNIT 24V
11
RELAY
RELAY
12
CABLEHARNESS
CABLE HARNESS
13
SOCKETHOUSING
SOCKET HOUSING
14
SOCKETCONNECTION
SOCKET CONNECTION
15
SOCKETCONNECTION
SOCKET CONNECTION
16
FLATPLUGHOUSING
FLAT PLUG HOUSING
17
FLATPLUGHOUSING
FLAT PLUG HOUSING
18
SOCKETHOUSING
SOCKET HOUSING
19
SOCKETHOUSING
SOCKET HOUSING
