1
2
3
4
4
5.1
5.2
6
7.1
7.2
8
9
11
12.1
12.2
13
Позиция на иллюстрации
Заводской номер детали
Название детали
1
11029748
RADIO-CASSETTE DECK
2
11029750
CONTROL DEVICE RADIO
3
15000370
MICROPHON
4
11067752
LOUDSPEAKER
5.1
11030224
TFT-MONITEUR 6,8
5.2
11073450
TFT-MONITOR 6,8
6
11029759
CD-PLAYER BLAUPUNKT
7.1
11063024
VIDEO
7.2
11030256
VIDEO
8
11029682
POWER AMPLIFICATION BOOSTER
9
11034308
GRILLE 170X42M
10
11029745
MICROPHON
11
11041602
ALARM SYSTEM TS 4000 UNI
12.1
11030262
CONVERTER composite RNPF02-3/24 V
12.2
11073504
SIGNAL PROCESSING PAL RGB CONVERTER
13
11030273
SWITCHBOX TYPE 2K
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
