Каталог запасных частей к технике: Neoplan N 516 SHD (MB, DC) E2. BRAKE SYSTEM CONNECTION

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
18
19
20
21
22
23
28
29
33
34
35
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
87
88
89
90
Позиция на иллюстрации Заводской номер детали Название детали
1 11018937 CONNECTOR
2 11018938 PUSH-IN-COUPLING
3 11018939 CONNECTOR
4 11018940 CONNECTOR
5 11018942 CONNECTOR 8X1,0, M12X1,5, NR7232
6 11018943 PUSH-IN-COUPLING
7 11018944 CONNECTOR
8 11018945 PUSH-IN-COUPLING
9 11018948 PUSH-IN-COUPLING
10 11018949 PUSH-IN-COUPLING
11 11018950 CONNECTOR
12 11018946 PUSH-IN-COUPLING
13 11018951 PUSH-IN-COUPLING
14 11018952 PUSH-IN-COUPLING
15 11018953 SCREW NECK
16 11018954 SCREWING STUD
17 11018955 SCREW NECK
18 11018957 PUSH-IN-COUPLING
19 11018957 PUSH-IN-COUPLING
20 11018958 PUSH-IN-COUPLING
21 11018959 PUSH-IN-COUPLING
22 11018960 PUSH-IN-COUPLING
23 11018974 TUBE CONNECTOR
24 11018975 TUBE CONNECTOR
25 11018976 TUBE CONNECTOR
26 11018977 TUBE CONNECTOR
27 11018916 TUBE CONNECTOR
28 11019203 TUBE CONNECTOR
29 11018995 QUICK CONNECTOR
30 11018996 PLUG CONNECTION
31 11018997 PLUG CONNECTION
32 11018998 QUICK CONNECTOR
33 11018999 QUICK CONNECTOR
34 11019133 PLUG-IN P5 WITH BULKHEAD
35 11018992 PLUG CONNECTION
36 11018993 CONNECTOR
37 11019199 CONNECTOR
38 11018994 CONNECTOR
39 11019000 90-PUSH-IN COUPLING FOR PLUG-IN P5
40 11019202 QUICK CONNECTOR
41 11019004 CONNECTOR FOR PLUG-IN P5
42 11019005 CONNECTOR
43 11019010 90-ELBOW FOR PLUG -IN P5
44 11019038 90-ELBOW 2XTHREAD
45 11019039 90-ELBOW 2XTHREAD
46 11019038 90-ELBOW 2XTHREAD
47 11019006 L-PIECE
48 11019134 UNION L FOR PLUG-IN P5
49 11019007 T-PIECE
50 11019011 T-PIECE
51 11019048 UNION T 3XTHREAD
52 11019049 UNION T 3XTHREAD
53 11019050 UNION T 3XTHREAD
54 11019054 UNION T 3XTHREAD WITH BRACKET
55 11019008 3-WAY ANGLE PIECE
56 110190135 4-WAY-CROSS-BLOCK FOR PLUG-IN P5
57 11019059 4-WAY-CROSS-BLOCK 4XTHREAD
58 11019060 4-WAY-CROSS-BLOCK 4XTHREAD
59 11019198 4-WAY-CROSS-BLOCK 4XTHREAD
60 11019019 SLEEVE
61 11019020 BULKHEAD
62 11018913 BULKHEAD STUD
63 11019018 BULKHEAD
64 11019022 BULKHEAD
65 11019023 BULKHEAD
66 11019021 SLEEVE
67 bulkhead bulkhead
68 11019016 90-ELBOW WITH BULKHEAD
69 11019042 90-ELBOW WITH BULKHEAD
70 11019015 90-ELBOW WITH BULKHEAD
71 11019017 90-ELBOW WITH BULKHEAD AND CONE
72 11018982 T-BULKHEAD
73 11019093 T-BULKHEAD
74 11018966 CHECK NUT
75 11019028 NUT
76 11019029 COUNTER NUT
77 11019031 COUNTER NUT
78 11018967 LOCKING NUT
79 11019032 LOCKING NUT
80 11019026 COLLAR
81 11019027 SOCKET JOINT
82 11018911 SCREW THREAD-SLEEVE
83 11018914 TRANSFER ADAPTER
84 11018915 TRANSFER ADAPTER
85 11019001 SCREW PLUG
86 11018965 PLUG
87 11019002 PLUG
88 11019003 PLUG
89 11019034 TEST CONNECTION
90 11019035 TEST POINT
