Каталог запасных частей к технике: Neoplan N 516 SHD (MAN) E2. VALVE SUPPORT TRAILING AXLE
1
2
2
3
3
4
4
5
6
6
6
6
7
8
8
8
8
8
9
10
10
11
11
12
12
12
13
13
13
13
14
14
14
15
15
16
16
16
17
18
19
20
21
22
23
24
24
25
25
26
26
27
28
29
30
31
32
33
34
35
36
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 11018583 | BRACKET | |
| 2 | 11018953 | SCREW NECK | |
| 3 | 11019199 | CONNECTOR | |
| 4 | 11019029 | COUNTER NUT | |
| 5 | 11019034 | TEST CONNECTION | |
| 6 | 11058556 | L-PICE | |
| 7 | 11017237 | PRESSURE CONVERTER | |
| 8 | 11057231 | NUT | |
| 9 | 11055520 | SCREW | |
| 10 | 11018939 | CONNECTOR | |
| 11 | 11018950 | CONNECTOR | |
| 12 | 11018994 | CONNECTOR | |
| 13 | 11018999 | QUICK CONNECTOR | |
| 14 | 11018953 | SCREW NECK | |
| 15 | 11017202 | RELAY VALVE | |
| 16 | 11018998 | QUICK CONNECTOR | |
| 17 | 11019024 | SLEEVE | |
| 18 | 11018716 | PRESSURE CONTROL VALVE | |
| 19 | 11019202 | QUICK CONNECTOR | |
| 20 | 11019011 | T-PIECE | |
| 21 | 11055044 | SCREW | |
| 22 | 11057233 | NUT | |
| 23 | 11017573 | 3/2 WAY SOLENOID VALVE | |
| 24 | 11018971 | PLUG CONNECTION | |
| 25 | 11018995 | QUICK CONNECTOR | |
| 26 | 11018944 | CONNECTOR | |
| 27 | 11019201 | F-PIECE | |
| 28 | 11055001 | SCREW | |
| 29 | 11019008 | 3-WAY ANGLE PIECE | |
| 30 | 11019100 | SLEEVE | |
| 31 | 11019028 | NUT | |
| 32 | 11017272 | SHUTTLE VALVE | |
| 33 | 11019021 | SLEEVE | |
| 34 | 11055520 | SCREW | |
| 35 | 11017222 | PRESSURE LIMITER | |
| 36 | 11018993 | CONNECTOR |
