Каталог запасных частей к технике: Neoplan N 3318 U E3. FRONT AXLE PARTS
11014713
1
2
4
5
6
7
7
8
9
10
10
10
10
11
11
12
12
13
14
15
16
16
17
17
18
19
20
21
21
22
22
23
24
25
26
27
28
29
30
31
32
33
33
33
33
34
35
210
310
320
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 11014713 | 11014713 | FRONT AXLE PARTS | |
| 1 | 11015757 | T-PIECE | |
| 2 | 11015755 | AXLE PUPES PART | |
| 4 | 11015832 | AXLE BRACKET | |
| 5 | 11015833 | AXLE BRACKET | |
| 6 | 11015386 | HUB ASSEMBLY | |
| 7 | 11015776 | KEYSTONE ABOVE | |
| 8 | 11015777 | KEYSTONE BELLOW RIGHT | |
| 9 | 11015778 | KEYSTONE BELLOW LEFT | |
| 10 | 11015009 | BRUCKET SILENT BLOCK | |
| 11 | 11015687 | BRUCKET SILENT BLOCK | |
| 12 | 11016043 | HOLDER | |
| 13 | 11055179 | SCREW | |
| 14 | 11054716 | SPRING WASHER | |
| 15 | 11055833 | NUT M14 | |
| 16 | 11054926 | SCREW M16X45MM | |
| 17 | 11054718 | SPRING WASHER M16 | |
| 18 | 11056226 | SCREW | |
| 19 | 11054562 | TAB WASHER DIN 25201 26,0X39,0X3,7 | |
| 20 | 11055310 | SCREW M18X210MM | |
| 21 | 11055287 | SCREW | |
| 22 | 11055841 | HEXAGON NUT | |
| 23 | 11055312 | SCREW | |
| 24 | 11055843 | NUT | |
| 25 | 11054722 | SPRING WASHER | |
| 26 | 11054562 | TAB WASHER DIN 25201 26,0X39,0X3,7 | |
| 27 | 11055919 | SCREW | |
| 28 | 11054564 | WASHER | |
| 29 | 11054565 | SPRING WASHER | |
| 30 | 11015688 | TENSIONING SCREW | |
| 31 | 11056426 | NUT | |
| 32 | 11054726 | SPRING WASHER | |
| 33 | 11054563 | WASHER | |
| 34 | 11055017 | SCREW | |
| 35 | 11056440 | HEXAGON NUT DIN 985 M6 | |
| 210 | 11015761 | STEARING GEAR PLATE | |
| 310 | 11015340 | SUPPORT | |
| 320 | 11015341 | SUPPORT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
