Каталог запасных частей к технике: Neoplan N 3318 U E3. COOLER
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
17
18
19
20
21
22
23
24
24
25
25
26
27
28
29
30
31
32
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | pump | hydraulic-pump | |
| 2 | 11009373 | flange-connection | |
| 3 | 11079515 | tube | |
| 4 | 11019807 | angle-flange-conne ction | |
| 5 | 11000424 | o-ring | |
| 6 | 11018095 | reduction-screwing | |
| 7 | 11080635 | hydraulic hose | |
| 8 | 11019802 | straigt union | |
| 9 | 11056630 | copper ring | |
| 10 | 11001425 | oil tanks | |
| 11 | 11022989 | bracket | |
| 12 | 11019798 | angle | |
| 13 | 11019800 | clamp | |
| 14 | 11019801 | oil dipstick | |
| 15 | 11019799 | vent filter | |
| 16 | 11017978 | angle screwing | |
| 17 | 11009373 | flange-connection | |
| 18 | 11076717 | tube | |
| 19 | 11019390 | hydraulic hose | |
| 20 | 11018054 | angle screwing | |
| 21 | 11080296 | straight union | |
| 22 | 11018834 | screwing | |
| 23 | 11076544 | angle bow | |
| 24 | 11018016 | angle screwing | |
| 25 | 11010954 | SCREWING | |
| 26 | 11010970 | check valve | |
| 27 | 11071907 | hydraulic motor | |
| 28 | 11007387 | screwing | |
| 29 | 11009373 | flange-connection | |
| 30 | 11076718 | brass pipe hydraulics | |
| 31 | 11076717 | tube | |
| 32 | 11076718 | brass pipe hydraulics |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
