Каталог запасных частей к технике: Neoplan N 3318 U E3. BRAKE SYSTEM
1
1
2
3
3
4
5
6
6
7
7
7
7
7
7
7
7
7
7
7
7
8
8
8
8
8
8
8
8
9
10
10
10
11
11
11
11
11
12
12
13
14
14
15
16
16
16
17
18
19
20
21
22
22
23
24
24
24
25
25
25
25
26
26
27
27
27
27
28
29
30
31
32
33
34
35
36
36
37
37
38
39
39
40
40
41
41
41
41
42
42
42
42
43
44
45
45
45
45.01
46
47
47
47
47
47
48
48
48
48
48
48
49
49
49
49
49
49
50
51
51
52
53
54
54
55
55
55
55
55
55
56
56
56
56
56
56
56
56
56
56
56
57
58
58
58
58
58
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 11018715 | SOLENOID VALVE | |
| 2 | 11017339 | pressure limiter | |
| 3 | 11017205 | QUICK RELAY VALVE | |
| 4 | 11017202 | RELAY VALVE | |
| 5 | 11017272 | SHUTTLE VALVE | |
| 6 | 11017274 | TWO WAY VALVE | |
| 7 | 11018998 | QUICK CONNECTOR | |
| 8 | 11018999 | QUICK CONNECTOR | |
| 9 | 11018992 | PLUG CONNECTION | |
| 10 | 11018993 | CONNECTOR | |
| 11 | 11019199 | CONNECTOR | |
| 12 | 11018994 | CONNECTOR | |
| 13 | 11019202 | QUICK CONNECTOR | |
| 14 | 11018943 | PUSH-IN-COUPLING | |
| 15 | 11018950 | CONNECTOR | |
| 16 | 11018953 | SCREW NECK | |
| 17 | 11018954 | SCREWING STUD | |
| 18 | 11019040 | arch | |
| 19 | 11019198 | 4-WAY-CROSS-BLOCK 4XTHREAD | |
| 20 | 11019008 | 3-WAY ANGLE PIECE | |
| 21 | 11019134 | UNION L FOR PLUG-IN P5 | |
| 22 | 11019011 | T-PIECE | |
| 23 | 11019009 | arch | |
| 24 | 11019004 | CONNECTOR FOR PLUG-IN P5 | |
| 25 | 11018965 | PLUG | |
| 26 | 11019003 | PLUG | |
| 27 | 11019028 | NUT | |
| 28 | 11019029 | COUNTER NUT | |
| 29 | 11019034 | TEST CONNECTION | |
| 30 | 11019022 | BULKHEAD | |
| 31 | 11019018 | BULKHEAD | |
| 32 | 11018913 | BULKHEAD STUD | |
| 33 | 11019013 | reduction | |
| 34 | 11018384 | neck | |
| 35 | 11017935 | neck | |
| 36 | 11019067 | neck | |
| 37 | 11019066 | u-piece | |
| 38 | 11017882 | SCREWING | |
| 39 | 11017730 | BRASS-RING 14MM | |
| 40 | 11017715 | RUBBER RING | |
| 41 | 11017731 | brass-wrestle | |
| 42 | 11017716 | sealing ring | |
| 43 | 11017728 | BRASS RING | |
| 44 | 11017713 | RUBBER RING | |
| 45 | 11016996 | hose | |
| 45.01 | 11017001 | hose | |
| 46 | 11016872 | BRAKE LINE | |
| 47 | 11016874 | HOSE | |
| 48 | 11016879 | POLY BRAKE AIR LINE | |
| 49 | 11016921 | POLY BRAKE LINE TUBE | |
| 50 | 11016891 | hose | |
| 51 | 11028652 | hose | |
| 52 | 11055535 | screw | |
| 53 | 11055538 | screw | |
| 54 | screw | screw | |
| 55 | 11056443 | NUT | |
| 56 | 11054597 | WASHER | |
| 57 | distance-husk | distance-husk | |
| 58 | 11068548 | bracket |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
