1
2
3
3.1
3.2
3
4
5
6
7
8
9
9
10
10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
1
11072196
MIDDLE CROSSHEAD
2
11021776
tractor towing device
3
11021785
back cross bar
3.1
11021779
TRACTOR TOWING DEVICE
3.2
11021823
tractor towing device
3
11076323
back cross bar
4
11021834
tractor towing device
5
11055312
SCREW
6
11054694
SPRING RING
7
11055843
NUT
8
11078261
screw
9
11055348
SCREW
10
11054600
WASHER
11
11056445
NUT
12
11048213
COVERING CAP
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
