Каталог запасных частей к технике: Neoplan N 116 (MAN) E3 (вар.). HEATING CIRCULATION
1
2
3
4
5
6
7
8
9
10
10
11
11
12
12
12
12
12
12
12
13
13
13
13
14
14
14
15
15
15
15
16
16
16
17
17
17
17
17
18
19
20
21
21.1
22
23
24
25
26
27
28
29
30
31
31
31
31
31
31
31
32
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 11033150 | frontbox cpl. | |
| 11060881 | 11060881 | FRONTBOX UNDER PART CPL. | |
| 11060883 | 11060883 | FRONTBOX UPPER PART CPL. | |
| 2 | 11034104 | heater | |
| 3 | 11034087 | CIRCULATING-AIR HEATING 24 V | |
| 4 | 11034733 | WATER STATION THERMO 300,068 | |
| 5 | 11033238 | AIR CONDITIONER | |
| 6 | 11033653 | compressor cpl. | |
| 11033538 | 11033538 | compressor cpl. | |
| 7 | 11074025 | BLISTER ABSORBER | |
| 8 | 11032299 | brass pipe | |
| 9 | 11032300 | brass return pipe | |
| 10 | 11008461 | SILICONE HOSE STRAIGHT 15 MM | |
| 11 | 11000840 | HOSE CLAMP | |
| 12 | 11059872 | INSULATING HOSE | |
| 13 | 11032526 | BRASS PIPE 28/1,5 | |
| 14 | 11008476 | SILICONE HOSE 28MM | |
| 15 | 11000842 | HOSE CLAMP | |
| 16 | 11032525 | BRASS PIPE | |
| 17 | 11059881 | INSULATING HOSE | |
| 18 | 11008386 | HOSE | |
| 19 | 11008478 | HOSE | |
| 20 | 11000843 | HOSE CLAMP | |
| 21 | 11022788 | CLAMP | |
| 21.1 | 11022815 | clamp | |
| 22 | 11055530 | screw | |
| 23 | 11054594 | WASHER | |
| 24 | 11054679 | SPRING RING | |
| 25 | 11055815 | NUT | |
| 26 | 11056776 | SCREW | |
| 27 | 11052459 | ADHESIVE TAPE | |
| 28 | 11028568 | cable clip | |
| 29 | 11034108 | PARALLEL-TURNKEY | |
| 30 | 11054751 | MEDIUM WASHER | |
| 31 | 11071427 | CONVECTOR | |
| 31.1 | 11071425 | CONVECTOR | |
| 32 | 11032529 | WATER PIPE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
