Каталог запасных частей к технике: King Long Автобус XMQ-6800Y. SWITCH AND INDICATOR LIGHT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 238200190 | Switch, daylight lamp | |
| 2 | 238200240 | Switch, annunciator | |
| 3 | 238200530 | Switch , back buzzer | |
| 4 | 238200640 | Switch , rear passenger door | |
| 5 | 238200620 | Switch , front passenger door | |
| 6 | 238200330 | Switch , ventilator | |
| 7 | 238200350 | Switch , front fog lamp | |
| 8 | 238202450 | Switch , rear fog lamp | |
| 9 | 238203210 | Switch , defroster | |
| 10 | 238200234 | Switch, defroster | |
| 11 | 238201860 | Switch , rearview mirror defroster | |
| 12 | 238201870 | Switch , horn change over | |
| 13 | 238200400 | Switch, tv overturn | |
| 14 | 238200760 | Switch , cruise setting | |
| 15 | 238200750 | Switch , cruise | |
| 16 | 238200650 | Switch , diagnose - english | |
| 17 | 238201810 | Switch, sunblind | |
| 18 | 238200230 | Switch, shoolbus | |
| 19 | 238202130 | Switch , power supply emergency- englis | |
| 20 | 238200300 | Switch , reading lamp | |
| 21 | 238200280 | Switch , luggage compartment lamp | |
| 22 | 238201050 | Engine alarm/ failure | |
| 23 | 238200605 | Mil | |
| 24 | 238203710 | Indicator light, wait for start | |
| 25 | 238200205 | Switch, fuel oil preheating | |
| 26 | 238200700 | Switch , sterilizing lamp |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
