Каталог запасных частей к технике: King Long Автобус XMQ-6800Y. PLUMBING, FUEL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 299009299 | Connector, qck disconnect | |
| 2 | 299001569 | Screw, hex flange head cap | |
| 3 | 299005708 | Screw, hex flange head cap | |
| 4 | 299005727 | Screw, hex flange head cap | |
| 5 | 299005841 | Valve, check | |
| 6 | 299001518 | Washer, sealing | |
| 7 | 299013891 | Washer, sealing | |
| 8 | 299014150 | Washer, sealing | |
| 9 | 299013892 | Connector, qck disconnect | |
| 10 | 299013911 | Washer, sealing | |
| 11 | 299013911 | Washer, sealing | |
| 12 | 299013929 | Clip | |
| 13 | 299014184 | Connector, male | |
| 14 | 299014188 | Adapter, fuel connector | |
| 15 | 299019665 | Tube, fuel supply | |
| 16 | 299014194 | Connector, qck disconnect | |
| 17 | 299019666 | Tube, fuel supply | |
| 18 | 299019667 | Tube, fuel drain | |
| 19 | 299019668 | Clamp, tube |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
