Каталог запасных частей к технике: King Long Автобус XMQ-6800Y. PARTS, PERFORMANCE

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
Позиция на иллюстрации Заводской номер детали Название детали
1 299016649 Piston, engine
2 299005670 Screw, hex flange head cap
3 299005706 Screw, hex flange head cap
4 299005708 Screw, hex flange head cap
5 299013847 Screw, hex flange head cap
6 299021123 Ring, retaining
7 299021123 Ring, retaining
8 299012922 Screw, hex flange head cap
9 299014135 Screw, hex flange head
10 299013884 Gear, camshaft
11 299013893 Screw, banjo connector
12 299014151 Bearing, connecting rod
13 299013897 Ring, compression piston
14 299014147 Dowel, ring
15 299014378 Ring, speed indicator
16 299019670 Camshaft
17 299005734 Dowel, pin
18 299014379 Camshaft
19 299013920 Screw, socket head cap
20 299013903 Ring, compression piston
21 299001621 Bearing, connecting rod
22 299013936 Pin, piston
23 299013940 Ring, oil piston
24 299019671 Tube, injector fuel suppl
28 299014382 Head, cylinder
29 299007830 Collet, valve
30 299007984 Seal, valve stem
31 299014139 Valve, exhaust
32 299014140 Valve, intake
33 299014142 Retainer, valve spring
34 299014168 Spring, valve
35 299014383 Head, cylinder
36 299014123 Plug, expansion
37 299012963 Plug, expansion
38 299005768 Plug, expansion
39 299005833 Plug, expansion
40 299005834 Plug, expansion
41 299014202 Insert, valve
42 299014203 Insert, valve
43 299014175 Rod, engine connecting
44 299014385 Gasket, cylinder head
45 299019672 Tube, injector fuel suppl
46 299019673 Manifold, fuel
47 299019674 Support, camshaft thrust
48 299014193 Clamp, injector
49 299014195 Retainer, inj ful sup cnr
50 299014338 Connector, inj fuel suppl
51 299013235 Injector
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
