Каталог запасных частей к технике: King Long Автобус XMQ-6800Y. MAIN SHAFT ASSY
1
2
4
4
4
4
4
4
4
4
4
4
4
4
4
9
9
9
9
9
9
9
9
9
9
10
11
11
11
11
12
13
15
15
15
17
17
17
20
25
31
35
36
41
42
44
44
45
45
45
45
45
45
47
51
52
58
60
61
62
62
63
63
64
64
65
65
67
81
82
82
83
84
85
86
87
90
91
95
96
97
115
116
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 217001446 | 217001446 | Hexagon nut | |
| 217000730 | 217000730 | Hex head bolt | |
| 1 | 217000286 | Circlip | |
| 2 | 217000141 | Needle bearing | |
| 4 | 217004874 | Snap ring | |
| 4 | 217004885 | Circlip | |
| 4 | 217004883 | Circlip | |
| 4 | 217005740 | Circlip | |
| 4 | 217004864 | Circlip | |
| 4 | 217004865 | Snap ring | |
| 4 | 217000282 | Circlip | |
| 4 | 217004881 | Snap ring | |
| 4 | 217004876 | Snap ring | |
| 4 | 217004878 | Snap ring | |
| 4 | 217004866 | Snap ring | |
| 4 | 217004880 | Snap ring | |
| 9 | 217000083 | Shim | |
| 9 | 217005741 | Shim | |
| 9 | 217000075 | Shim | |
| 9 | 217000076 | Shim | |
| 9 | 217000078 | Shim | |
| 9 | 217000082 | Shim | |
| 9 | 217000081 | Shim | |
| 9 | 217000080 | Shim | |
| 9 | 217000077 | Shim | |
| 9 | 217000079 | Shim | |
| 10 | 217000199 | Synchronizer hub, 6th speed | |
| 11 | 217004611 | Synchronizer ring, 5th/6th speed | |
| 12 | 217000244 | Synchronizer tooth holder, 5th/6th speed | |
| 13 | 217004574 | Synchronizer sliding sleeve, 5th/6th spee | |
| 15 | 217000241 | Comperssion spring | |
| 17 | 217000240 | Plunger | |
| 18 | 217000259 | Needle bearing, 1st speed | |
| 20 | 217000218 | Sliding sleeve, 3rd/4th/5th/6th speed | |
| 25 | 217000246 | Synchronizer hub, 5th speed | |
| 31 | 217000152 | 6th speed gear | |
| 35 | 217000167 | Needle bearing , 5th speed | |
| 36 | 217000151 | Inner seat ring, 4th speed bearing | |
| 41 | 217000150 | 4th speed gear | |
| 42 | 217000168 | Needle bearing , 4th speed gear | |
| 44 | 217003019 | Clutch body | |
| 45 | 217000294 | Circlip | |
| 45 | 217000297 | Circlip | |
| 45 | 217000296 | Circlip | |
| 45 | 217000293 | Circlip | |
| 45 | 217000295 | Circlip | |
| 47 | 217000217 | Synchronizer tooth holder, 3rd/4th spee | |
| 51 | 217000149 | 3rd speed gear | |
| 52 | 217000215 | Needle bearing, 3rd speed gear | |
| 58 | 217008552 | Output shaft | |
| 60 | 217000143 | Needle bearing , 2nd speed gear | |
| 61 | 217000148 | 2nd speed gear | |
| 62 | 217000039 | Ring gear | |
| 63 | 217000229 | Syochrowizer ring | |
| 64 | 217002956 | Outer ring | |
| 65 | 217002954 | Inner cone ring | |
| 67 | 217000258 | L/2 g synchronzer body | |
| 75 | 217000237 | L/2 g sliding sleeve | |
| 81 | 217005742 | Needle cace | |
| 82 | 217000153 | 1th spur gear | |
| 82 | 217000154 | Bush | |
| 83 | 217005743 | Revorse gear clutcu body | |
| 84 | 217000154 | Bush | |
| 85 | 217000146 | Bush | |
| 86 | 217000145 | Needle cace | |
| 87 | 217000144 | Spur gear | |
| 90 | 217000043 | Ball bearing | |
| 91 | 217000276 | Snap ring | |
| 95 | 217000197 | Speedometer worm | |
| 96 | 217000224 | Output flange | |
| 97 | 217008024 | Washer | |
| 115 | SCREW | Screw, hex flange head cap | |
| 116 | 217008025 | Lockking plate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
