Каталог запасных частей к технике: King Long Автобус XMQ-6800Y. FRONT AXLE
1
2
3
4
5
6
7
8
8
9
9
10
11
12
12
13
14
15
16
17
18
18
19
20
21
21
21
21
21
21
21
21
22
23
24
25
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 224003539 | 224003539 | Parking sheet | |
| 230000867 | 230000867 | Cup leater | |
| 230000774 | 230000774 | Front right brake chamber assy | |
| 1 | 230000512 | Front wheel hub cover | |
| 2 | 230000471 | Paper gasket | |
| 3 | 230000341 | Hex slotted flat nut | |
| 4 | 230000340 | Retaining plate | |
| 5 | 230003689 | Front left/right wheel hub assembly | |
| 6 | 230000472 | The front hub oil seal seat assembly | |
| 7 | 230000310 | Stud | |
| 8 | 230002092 | Left steering knuckle assy | |
| 8 | 230002090 | Right steering knuckle assy | |
| 9 | 230000375 | Upper left steering knuckle arm | |
| 10 | 230000020 | Steering locating screw | |
| 11 | 230001010 | Wedge lock pin | |
| 12 | 224003556 | Front wheel brake assy | |
| 12 | 224003555 | Front wheel brake pipe assy | |
| 13 | Hexagonbolt | Hexagon bolt-fixing brake | |
| 14 | 230000269 | Sensor | |
| 15 | 230000366 | Front shaft | |
| 16 | 230000575 | Tie rod assy | |
| 17 | 230002091 | Thrust bearing | |
| 18 | 230000363 | Right steering knuckle arm | |
| 18 | 230000362 | Left steering knuckle arm | |
| 19 | Steeringcover | Steering upper cover | |
| 20 | Papergasket | Paper gasket | |
| 21 | 230000298 | Adjusting washer | |
| 21 | 230000299 | Adjusting washer | |
| 21 | 230000300 | Adjusting washer | |
| 21 | 230000301 | Adjusting washer | |
| 21 | 230000302 | Adjusting washer | |
| 21 | 230000303 | Adjusting washer | |
| 21 | 230000297 | Adjusting washer | |
| 21 | 230000296 | Adjusting washer | |
| 22 | 230002988 | King pin | |
| 23 | 230000306 | Oil seal assy | |
| 24 | 230000307 | Bolt | |
| 25 | 230000773 | Front left brake chamber assy |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
