Каталог запасных частей к технике: King Long Автобус XMQ-6800Y. BRAKE PIPELINE
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 235500820 | 235500820 | Brake master cylinder muffler | |
| 235500190 | 235500190 | The valve assembly | |
| 370800028 | 370800028 | Brake pipe | |
| 370800026 | 370800026 | Brake pipe | |
| 370800027 | 370800027 | Pipe assy | |
| 370800025 | 370800025 | Pipe assy | |
| 361300120 | 361300120 | Brake hose | |
| 361300090 | 361300090 | Brake hose | |
| 361300080 | 361300080 | Brake hose | |
| 313103020 | 313103020 | Bracket-air reservior | |
| 313100190 | 313100190 | Support - gas reservoir | |
| 380200800 | 380200800 | Pull belt | |
| 1 | 235400020 | Brake master cylinder assy | |
| 2 | 235500860 | Hand brake switch | |
| 3 | 235500044 | Water drain valve | |
| 4 | 235700059 | Air reservior assy | |
| 5 | 238300330 | Pressure sensors | |
| 6 | 235500310 | Quick release valve | |
| 7 | 238300370 | Switch, manual brake | |
| 8 | 235600020 | Abs solenoid valve | |
| 9 | 235200020 | Condenser | |
| 10 | 238300300 | Brake lamp switch | |
| 11 | 235500320 | Valve assembly, two-way | |
| 12 | 235500006 | Relay valve | |
| 13 | 235700110 | Regenerative tank assembly | |
| 14 | 235500010 | Water drain valve | |
| 15 | 235500130 | Two-way valve | |
| 16 | 235600030 | Asr valve | |
| 17 | 238600550 | Ecu, abs | |
| 18 | 235500350 | Differential relay valve | |
| 19 | 235200130 | Air dryer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
