Позиция на иллюстрации
Заводской номер детали
Название детали
279200870
279200870
Probe, monitor
283800060
283800060
Medicine box
1
282100073
Inner rear view mirror
2
282500063
Fire extinguisher assembly
3
282500090
Emergency hammer
4
282300199
Curtain hooks
5
282300198
Curtain hooks
6
282301724
Curtain
7
431250010
Aluminum section, curtain
8
282301524
Curtain
9
239300040
Sign
10
282300022
Sun blind
11
282300400
Side sunproof curtain, driver
