REARVIEW MIRROR AND WIPER
SLEEPER COMPARTMENT ACCESSORIES
LIGHTING SYSTEM (1)
ELECTRICAL EQUIPMENT (2)
HARNESS, ELECTRICAL COMPONENTS
FUSE BOX
SWITCH CONTROL BOX
ALTERNATOR ASSY
ALTERNATOR FOR AIR CONDITION
INSTRUMENT DESK
SWITCH AND INDICATOR LIGHT
DEFROSTING SYSTEM
COMPRESSOR INSTALLATION
AIR CONDITIONER WIRING HARNESS SKETCH
CONDENSER COMPONENTS
AIR CONDITIONER, EVAPORATOR SYSTEM
AIR CONDITIONER, EXTERIOR PIPELINE LINK
KL-03N THE MAIN COMPONENTS
1
2
3A
3B
4
4
5
5
6
6
7
8
9
9
10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
1
282200087
Rearview mirror, right exterior
2
282200086
Rearview mirror, left exterior
3A
282000515
Aluminum seat, right
3B
282000516
Aluminum seat, left
4
282000251
Mirror, bottom view
5
282000331
Motor, rearview mirror
6
282000252
Mirror, main
279500079
279500079
Wiper
7
282000127
Motor, wiper
8
279000342
Connecting rod
9
279000084
Wiper brade
10
279000053
Wiper arm, rh
11
279000052
Wiper arm, lh
12
279500084
Syringe
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
