Каталог запасных частей к технике: King Long Автобус XMQ-6129Y. INNER TRIM (2)
1
2
3
4
5
6
6
7
8
9
10
10
11
11
12
13
14
15
16
17
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 251500002 | 251500002 | Sealing head, heater shield | |
| 251508940 | 251508940 | Sealing head | |
| 251508930 | 251508930 | Sealing head | |
| 251508670 | 251508670 | Floor decorative fitting | |
| 251509394 | 251509394 | Aluminum section, floor lamp | |
| 431030010 | 431030010 | Aluminum section | |
| 251500213 | 251500213 | Sealing head, heater shield | |
| 251507940 | 251507940 | End cover, passenger seat section | |
| 1 | 251500001 | Sealing head, heater shield | |
| 2 | 251500453 | Mouting aluminium section, seat | |
| 3 | 431340010 | Mouting aluminium section, seat | |
| 4 | 251501120 | Floor decorative fitting | |
| 5 | 281600081 | Grid, air recirculated | |
| 6 | 257300012 | Scuttle | |
| 7 | 251400689 | Access cover | |
| 8 | 251400688 | Access cover | |
| 9 | 251400240 | Access cover | |
| 10 | 445000400 | Caution rubber strip, aboarding | |
| 11 | 431650020 | Step lamp | |
| 12 | 251508140 | Aluminum section, floor lamp | |
| 13 | 380501290 | Floor decorative fitting | |
| 14 | 251507950 | Floor mound layer corner | |
| 15 | 723000010 | Floor pressing strip accessories | |
| 16 | 431330020 | Aluminum section | |
| 17 | 251301030 | Floor cover |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
