Каталог запасных частей к технике: King Long Автобус XMQ-6129Y. GEAR SHIFT HOUSING
10
20
30
30
30
32
34
34
34
36
40
42
42
42
44
46
46
46
80
98
110
150
150
154
154
154
154
154
160
170
180
230
240
400
410
414
416
420
430
440
450
460
470
474
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 217004505 | 217004505 | Sealing ring | |
| 217003399 | 217003399 | Washer | |
| 217003399 | 217003399 | Washer | |
| 217003399 | 217003399 | Washer | |
| 217003399 | 217003399 | Washer | |
| 217003399 | 217003399 | Washer | |
| 217003399 | 217003399 | Washer | |
| 217003399 | 217003399 | Washer | |
| 217003399 | 217003399 | Washer | |
| 10 | 217003016 | Gearhousingshift | |
| 20 | 217003008 | Gasket | |
| 30 | 217005541 | Hexagon bolt | |
| 32 | 217005541 | Hexagon bolt | |
| 34 | 217005541 | Hexagon bolt | |
| 36 | 217005541 | Hexagon bolt | |
| 40 | 217005541 | Hexagon bolt | |
| 42 | 217005541 | Hexagon bolt | |
| 44 | 217005541 | Hexagon bolt | |
| 46 | 217005541 | Hexagon bolt | |
| 80 | 217004514 | Shiftinginterlock | |
| 98 | 217006295 | Screw plug | |
| 110 | 217002960 | Detent plunger | |
| 150 | 217005134 | Stop pin | |
| 154 | 217005110 | Retaining ring | |
| 154 | 217005111 | Retaining ring | |
| 154 | 217005112 | Retaining ring | |
| 154 | 217005113 | Retaining ring | |
| 154 | 217002916 | Retaining ring | |
| 160 | 217003014 | Gasket | |
| 170 | 217003015 | Cover | |
| 180 | 217004388 | Hexagon bolt | |
| 230 | 217003013 | Gear shift shaft | |
| 240 | 217002951 | Protecting cap | |
| 400 | 217002924 | Cylroller | |
| 410 | 217003010 | Detent part | |
| 414 | 217004577 | Slotpin | |
| 416 | 217004578 | Slotpin | |
| 420 | 217003009 | Driver | |
| 430 | 217003009 | Driver | |
| 440 | 217003009 | Driver | |
| 450 | 217003009 | Driver | |
| 460 | 217002923 | Needle sleeve | |
| 470 | 217002997 | Detent part | |
| 474 | 217005131 | Slotpin |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
