Каталог запасных частей к технике: King Long Автобус XMQ-6129Y. FRONT AXLE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 230000408 | 230000408 | Steering knuckle | |
| 230000384 | 230000384 | Steering knuckle adjusting washer | |
| 230000385 | 230000385 | Steering knuckle adjusting washer | |
| 230000381 | 230000381 | Lower bushing | |
| 230000386 | 230000386 | Steering knuckle adjusting washer | |
| 230000387 | 230000387 | Steering knuckle adjusting washer | |
| 230000388 | 230000388 | Steering knuckle adjusting washer | |
| 230000389 | 230000389 | Steering knuckle adjusting washer | |
| 230000390 | 230000390 | Steering knuckle adjusting washer | |
| 224001745 | 224001745 | Abs sensor | |
| 224001746 | 224001746 | Sensor bush | |
| 230000783 | 230000783 | Front right brake chamber assy | |
| 230000851 | 230000851 | Brake disc assy | |
| 230000759 | 230000759 | Right caliper | |
| 224002976 | 224002976 | Brake pad | |
| 1 | 224002733 | Hexagon nut | |
| 2 | 540316000 | Heavy-duty spring washer | |
| 3 | 230000758 | Left caliper | |
| 4 | 230000782 | Front left brake chamber assy | |
| 5 | 230000593 | Tie rod assy | |
| 6 | 230001113 | Grease fitting | |
| 7 | Pipe | Oil pipe | |
| 8 | 230000396 | Bolt-dust cap | |
| 9 | 230000395 | Kingpin cover | |
| 10 | 230000194 | Seal gasket | |
| 11 | 230000409 | Steering knuckle kingpin | |
| 12 | 230000380 | Upper bushing | |
| 13 | 230000395 | Kingpin cover | |
| 14 | Bolt | Bolt | |
| 15 | 230000433 | Front axle | |
| 16 | Seat | Push rod seat | |
| 17 | Pin | Cylindrical pin | |
| 18 | 534110000 | Hexagon nut-lock pin | |
| 19 | 230000383 | Steering knuckle adjusting washer | |
| 20 | 230000391 | Lockpin | |
| 21 | 230000391 | Lockpin | |
| 22 | 230000394 | Pushing lock bearing assy | |
| 23 | 230000410 | Left steering knuckle arm | |
| 24 | 230000413 | Drag rod arm | |
| 25 | 230000412 | Screw | |
| 26 | Cable | Cable | |
| 27 | 230000412 | Screw | |
| 28 | 230000393 | Screw plug | |
| 29 | 230000392 | Steering limiting screw | |
| 30 | 230000406 | Locking nut | |
| 31 | 230000411 | Right steering knuckle arm | |
| 32 | 230000393 | Screw plug | |
| 33 | 230001502 | Steering knuckle | |
| 34 | Hexagonbolt | Hexagon bolt-fixing brake | |
| 35 | Pin | Cylindrical pin | |
| 36 | Screw | Screw plug | |
| 37 | 230000431 | Locking bolt | |
| 38 | Bolt | Bolt | |
| 39 | 230000492 | Front hub seal assy | |
| 40 | 230000500 | Oil seal seat | |
| 41 | 230000483 | Front hub inner bearing assy | |
| 42 | 230000855 | Front brake disc | |
| 43 | Ring | Abs front ring | |
| 44 | 230000832 | Front wheel bolt | |
| 45 | 230000496 | Front hub | |
| 46 | 224001379 | Tyre nut | |
| 47 | 230000516 | Bolt | |
| 48 | 230000485 | Front hub outer bearing assy | |
| 49 | 230000404 | Washer | |
| 50 | 230000405 | Slotted thin nut | |
| 51 | 230001105 | Split pin | |
| 52 | 230000490 | Gasket | |
| 53 | 230000489 | Hub cup | |
| 54 | 230001095 | Heavy-duty spring washer | |
| 55 | 224002132 | Bolt |
