Каталог запасных частей к технике: King Long Автобус XMQ-6129Y. ENGINE CONTROL MODEL
1
2
3
4
4
5
6
7
7
8
9
10
11
11
12
13
14
15
16
17
18
19
20
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 299009316 | Module, electronic contro | |
| 2 | 299021948 | Module, electronic contro | |
| 3 | 299019159 | Sensor, position | |
| 4 | 299019153 | Sensor, position | |
| 5 | 299001569 | Screw, hex flange head cap | |
| 6 | 299001569 | Screw, hex flange head cap | |
| 7 | 299013847 | Screw, hex flange head cap | |
| 8 | 299013851 | Screw, hex flange head cap | |
| 9 | 299005749 | Screw, hex flange head cap | |
| 10 | 299013868 | Screw, captive washer cap | |
| 11 | 299013874 | Screw, studded flange cap | |
| 12 | 299013886 | Isolator, vibration | |
| 13 | 299013887 | Isolator, vibration | |
| 14 | 299013888 | Screw, socket head cap | |
| 15 | 299013905 | Wire, ground | |
| 16 | 299030889 | Sensor, prs temperature | |
| 17 | 299013967 | Sensor, temperature | |
| 18 | 299014899 | Dataplate | |
| 19 | 299030890 | Sensor, pressure | |
| 20 | 299019147 | Sensor, pressure |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
