Каталог запасных частей к технике: King Long Автобус XMQ-6129Y5. WIPER AND REARVIEW MIRROR
a
1
2
3
3
4
5
6
7
7
7
b
8
9
10
11
12
13
13
14
15
16
16
17
17
18
18
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| a | 279500131 | Wiper | |
| 1 | 282000127 | Motor, wiper | |
| 2 | 279000140 | Connecting rod | |
| 3 | 279000085 | Wiper brade | |
| 4 | 279000074 | Wiper arm, rh | |
| 5 | 279000073 | Wiper arm, lh | |
| 6 | 279500056 | Syringe | |
| 7 | 279000088 | Bowl cover | |
| b | 279500090 | Wiper | |
| 8 | 279000057 | Motor, wiper | |
| 9 | 279000198 | Connecting rod | |
| 10 | 282000116 | Wiper kettle | |
| 11 | 279000196 | Wiper arm | |
| 12 | 279000085 | Wiper brade | |
| 279000253 | 279000253 | Wiper nozzle, r | |
| 279000255 | 279000255 | Wiper nozzle, l | |
| 282200230 | 282200230 | Rearview mirror, outer, l | |
| 282200301 | 282200301 | Rearview mirror, outer, r | |
| 13 | 282000327 | Main rearview mirror and backplane assembl | |
| 14 | 282000197 | Support, long | |
| 15 | 282000219 | Fill blind mirror | |
| 16 | 282000194 | Shell, anticollision | |
| 17 | 282000192 | Shield | |
| 18 | 282000190 | Primary mirror shell cover | |
| 282000326 | 282000326 | Electrokinetic regulator |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
