Каталог запасных частей к технике: King Long Автобус XMQ-6127J. SWITCH AND INDICATOR LIGHT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 3800101-002LU | Switch, retarder turn off | |
| 2 | 3800102 | Switch , daylight lamp | |
| 3 | 3800103-003 | Switch, emergency lamp | |
| 4 | 3800138LU | Switch, lifter | |
| 5 | 3800139LU | Switch, body return | |
| 6 | Switch | Hand sub-dial switch assembly | |
| 7 | 3800107 | Switch , ventilator | |
| 8 | 3800108 | Switch , front fog lamp | |
| 9 | 3800109 | Switch , rear fog lamp | |
| 10 | 3800115 | Switch , back buzzer | |
| 11 | 3800138-005 | Switch, kneeling | |
| 12 | 3800125-004 | Switch, cruise | |
| 13 | 3800126 | Switch , cruise setting | |
| 14 | 3800134LU | Switch, passenger door | |
| 15 | 3800221LU | Switch, outer guidepost | |
| 16 | 3800223LU | Switch, inner guidepost | |
| 17 | 3800128-002LU | Switch, emergency | |
| 18 | 238202120 | Switch, buzzer | |
| 19 | Switch | Hand sub-dial switch assembly | |
| 20 | 3800114-001 | Switch, horn change over | |
| 21 | 3800141-021LU | Indicator lamp, transmission oil temp too | |
| 22 | 279400900 | Switch, disinfect-english | |
| 23 | Switch | Hand sub-dial switch assembly | |
| 24 | Switch | Hand sub-dial switch assembly |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
