Каталог запасных частей к технике: King Long Автобус XMQ-6127J. REAR AXLE 24ZS19H-00005-B
1
2
3
4
4
5
6
7
8
8
9
10
11
12
13
14
15
16
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| Q40520 | Q40520 | Spring washer | |
| 1 | 24N-01068 | Air breather | |
| 2 | 24N01065 | Plug | |
| 3 | 3530ZS19-001/002 | Left/ right brake chamber | |
| 4 | Bolt | Bolt | |
| 4 | Washer | Washer | |
| 5 | Q151B2060-0H1 | Bolt | |
| 6 | 31XZB-04022 | Inner ring, rear hub inner bearing | |
| 7 | 31XZB-04075 | Seat ring , oil seal | |
| 8 | 31NP-03054 | Front wheel nut | |
| 8 | Nut | Nut | |
| 9 | 31N-04022 | Inner ring, rear hub out bearing | |
| 10 | 24ZS01-03065-A/03066-A | Half axle | |
| 11 | 24ZCS01-01076 | Adjusting nut | |
| 12 | 3502ZS19E-026/126 | Transitional disk | |
| 13 | 35ZS19-02075 | Brake disc | |
| 14 | 31XZB-04080 | Oil seal | |
| 15 | Caliper | Caliper body | |
| 16 | 31NP-03059 | Bolt | |
| 16 | Washer | Washer | |
| 17 | 31ZS19E-04015 | Hub | |
| 18 | 31NP-04051 | Tire bolt | |
| 19 | Washer | Washer | |
| 20 | 24XZB-03064 | Axle shaft gasket | |
| 21 | 24XZB-01081-B | Lock washer | |
| 22 | 24XZB-01090 | Half axle oil seal assy | |
| 23 | 24N-03063 | Bolt, half axle | |
| 24 | 2401ZS19H-010-B | Axle housing | |
| 25 | 24ZHS01-01062 | Bolt | |
| 26 | 24ZS01-01063 | Nut | |
| 27 | Q40520 | Spring washer | |
| 28 | 24N-01072 | Oil drain plug | |
| 29 | 31XZB-04021 | Exterior ring, rear hub inner bearing | |
| 30 | 31N-04021 | Exterior ring, rear hub out bearing |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
