Каталог запасных частей к технике: King Long Автобус XMQ-6127J. OUTPUT
10
14
14
14
20
20
20
50
60
60
60
66
66
66
72
72
72
78
78
78
84
84
84
90
90
90
96
96
96
102
102
102
108
108
108
114
114
114
120
120
120
126
126
126
132
132
132
138
138
138
144
144
144
150
150
150
156
156
160
160
160
162
162
162
166
166
166
200
200.110
200.120
200.130
200.130
200.130
200.140
200.140
200.150
200.150
200.160
200.200
210
220
222
240
250
260
300
300
300
300
300
300
300.20
310
330
356
380
400
410
420
430
430
430
440
454
454
454
464
464
464
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10 | 4149.203.023 | Output cover | |
| 14 | 0636.305.067 | Screw plug | |
| 14 | 0634.801.057 | Sealing ring | |
| 20 | 0750.111.018 | Shaft seal | |
| 20 | 0750.199.019 | Grease | |
| 50 | 4139.301.618 | Gasket | |
| 60 | 0636.010.378 | Hexagon bolt | |
| 60 | 0630.001.048 | Washer | |
| 66 | 0636.010.071 | Hexagon bolt | |
| 66 | 0630.001.048 | Washer | |
| 72 | 0636.010.071 | Hexagon bolt | |
| 72 | 0630.001.048 | Washer | |
| 78 | 0636.010.071 | Hexagon bolt | |
| 78 | 0630.001.048 | Washer | |
| 84 | 0636.010.378 | Hexagon bolt | |
| 84 | 0630.001.048 | Washer | |
| 90 | 0636.010.071 | Hexagon bolt | |
| 90 | 0630.010.026 | Washer | |
| 96 | 0636.010.071 | Hexagon bolt | |
| 96 | 0630.010.026 | Washer | |
| 102 | 0636.010.071 | Hexagon bolt | |
| 102 | 0630.010.026 | Washer | |
| 108 | 0636.010.071 | Hexagon bolt | |
| 108 | 0630.010.026 | Washer | |
| 114 | 0636.010.379 | Hexagon bolt | |
| 114 | 0630.001.048 | Washer | |
| 120 | 0636.010.378 | Hexagon bolt | |
| 120 | 0630.001.048 | Washer | |
| 126 | 0636.010.378 | Hexagon bolt | |
| 126 | 0630.001.048 | Washer | |
| 132 | 0636.010.071 | Hexagon bolt | |
| 132 | 0630.010.026 | Washer | |
| 138 | 0636.010.071 | Hexagon bolt | |
| 138 | 0630.010.026 | Washer | |
| 144 | 0636.010.071 | Hexagon bolt | |
| 144 | 0630.010.026 | Washer | |
| 150 | 0636.010.071 | Hexagon bolt | |
| 150 | 0630.010.026 | Washer | |
| 156 | 0636.010.378 | Hexagon bolt | |
| 156 | 0630.001.048 | Washer | |
| 160 | 0636.010.378 | Hexagon bolt | |
| 160 | 0630.001.048 | Washer | |
| 162 | 0636.010.379 | Hexagon bolt | |
| 162 | 0630.001.048 | Washer | |
| 166 | 0636.010.378 | Hexagon bolt | |
| 166 | 0630.001.048 | Washer | |
| 200 | 4149.203.016 | Planetary drive | |
| 200.110 | 4149.203.014 | Planet carrier | |
| 200.120 | 4139.333.593 | Bearing pin | |
| 200.130 | 0735.320.480 | Needle cage | |
| 200.130 | 0735.321.461 | Needle cage | |
| 200.140 | 4149.233.013 | Planet gear set | |
| 200.140 | 4139.203.136 | Planet gear set | |
| 200.150 | 4149.303.023 | Thrust washer | |
| 200.160 | 0501.315.917 | Slotpin | |
| 200.200 | 0750.115.518 | Needle sleeve | |
| 210 | 0730.105.229 | Spacing washer | |
| 210 | 0730.105.228 | Spacing washer | |
| 210 | 0730.105.227 | Spacing washer | |
| 210 | 0730.110.828 | Spacing washer | |
| 210 | 0730.105.226 | Spacing washer | |
| 210 | 0730.110.827 | Spacing washer | |
| 210 | 0730.105.225 | Spacing washer | |
| 210 | 0730.110.826 | Spacing washer | |
| 210 | 0730.105.224 | Spacing washer | |
| 210 | 0730.109.936 | Spacing washer | |
| 210 | 0730.105.223 | Spacing washer | |
| 210 | 0730.109.935 | Spacing washer | |
| 210 | 0730.105.222 | Spacing washer | |
| 210 | 0730.109.934 | Spacing washer | |
| 210 | 0730.105.221 | Spacing washer | |
| 210 | 0730.109.933 | Spacing washer | |
| 210 | 0730.103.511 | Spacing washer | |
| 210 | 0730.109.932 | Spacing washer | |
| 210 | 0730.103.512 | Spacing washer | |
| 210 | 0730.109.931 | Spacing washer | |
| 210 | 0730.103.513 | Spacing washer | |
| 210 | 0730.109.930 | Spacing washer | |
| 210 | 0730.103.514 | Spacing washer | |
| 210 | 0730.109.929 | Spacing washer | |
| 210 | 0730.103.515 | Spacing washer | |
| 210 | 0730.109.928 | Spacing washer | |
| 210 | 0730.103.516 | Spacing washer | |
| 210 | 0730.109.927 | Spacing washer | |
| 210 | 0730.103.517 | Spacing washer | |
| 210 | 0730.109.926 | Spacing washer | |
| 210 | 0730.103.518 | Spacing washer | |
| 210 | 0730.103.519 | Spacing washer | |
| 210 | 0730.103.272 | Spacing washer | |
| 210 | 0730.103.273 | Spacing washer | |
| 210 | 0730.103.274 | Spacing washer | |
| 210 | 0730.103.275 | Spacing washer | |
| 210 | 0730.103.276 | Spacing washer | |
| 210 | 0730.103.277 | Spacing washer | |
| 210 | 0730.103.278 | Spacing washer | |
| 210 | 0730.103.279 | Spacing washer | |
| 210 | 0730.103.362 | Spacing washer | |
| 220 | 0750.117.625 | Tarollbearing | |
| 222 | 0730.009.583 | Washer | |
| 240 | 4149.303.013 | Toothed ring | |
| 250 | 0730.103.586 | Washer | |
| 250 | 0730.008.869 | Washer | |
| 250 | 0730.103.587 | Washer | |
| 250 | 0730.106.668 | Washer | |
| 250 | 0730.103.588 | Washer | |
| 250 | 0730.106.667 | Washer | |
| 250 | 0730.106.666 | Washer | |
| 250 | 0730.008.868 | Washer | |
| 250 | 0730.103.589 | Washer | |
| 250 | 0730.103.590 | Washer | |
| 250 | 0730.103.591 | Washer | |
| 260 | 0750.117.621 | Tarollbearing | |
| 300 | 4139.203.033 | Output flange | |
| 300.20 | 0736.020.126 | Hexagon bolt | |
| 310 | 4139.303.239 | Washer | |
| 330 | 0636.011.641 | Hexagon bolt | |
| 356 | 0501.214.772 | Pulse sensor | |
| 380 | 0501.314.432 | Indtransmitter | |
| 0730.008.442 | 0730.008.442 | Washer | |
| 0730.008.441 | 0730.008.441 | Washer | |
| 0730.008.440 | 0730.008.440 | Washer | |
| 0730.008.439 | 0730.008.439 | Washer | |
| 0730.008.438 | 0730.008.438 | Washer | |
| 0730.008.437 | 0730.008.437 | Washer | |
| 0730.008.436 | 0730.008.436 | Washer | |
| 0730.008.435 | 0730.008.435 | Washer | |
| 0730.008.434 | 0730.008.434 | Washer | |
| 0730.008.433 | 0730.008.433 | Washer | |
| 0730.008.432 | 0730.008.432 | Washer | |
| 0730.008.431 | 0730.008.431 | Washer | |
| 0730.008.430 | 0730.008.430 | Washer | |
| 0730.008.429 | 0730.008.429 | Washer | |
| 0730.008.428 | 0730.008.428 | Washer | |
| 0730.009.198 | 0730.009.198 | Washer | |
| 0730.008.427 | 0730.008.427 | Washer | |
| 0730.009.197 | 0730.009.197 | Washer | |
| 0730.008.426 | 0730.008.426 | Washer | |
| 0730.009.196 | 0730.009.196 | Washer | |
| 0730.008.425 | 0730.008.425 | Washer | |
| 0730.008.424 | 0730.008.424 | Washer | |
| 0730.009.195 | 0730.009.195 | Washer | |
| 0730.008.423 | 0730.008.423 | Washer | |
| 0730.009.194 | 0730.009.194 | Washer | |
| 0730.008.422 | 0730.008.422 | Washer | |
| 0730.009.193 | 0730.009.193 | Washer | |
| 0730.008.421 | 0730.008.421 | Washer | |
| 0730.009.192 | 0730.009.192 | Washer | |
| 0730.008.420 | 0730.008.420 | Washer | |
| 0730.009.191 | 0730.009.191 | Washer | |
| 0730.008.419 | 0730.008.419 | Washer | |
| 0730.008.418 | 0730.008.418 | Washer | |
| 0730.008.417 | 0730.008.417 | Washer | |
| 0736.101.359 | 0736.101.359 | Torx screw | |
| 0634.313.016 | 0634.313.016 | O-ring | |
| 400 | 4149.206.102 | Cable connect | |
| 410 | 4149.303.024 | Cover | |
| 420 | 0634.316.248 | O-ring | |
| 430 | 0636.015.489 | Hexagon bolt | |
| 430 | 0630.001.076 | Washer | |
| 440 | 4181.212.006 | Valve | |
| 454 | 0636.305.067 | Screw plug | |
| 454 | 0634.801.057 | Sealing ring | |
| 464 | 0636.305.067 | Screw plug | |
| 464 | 0634.801.057 | Sealing ring |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
