Каталог запасных частей к технике: King Long Автобус XMQ-6127J. HEAT EXCHANGER
10
12
12
14
16
20
50
50
50
56
56
62
62
62
68
68
68
74
74
74
80
80
80
86
86
86
100
120
120
220
250
250.110
250.120
250.130
250.140
250.150
250.150
250.160
250.160
250.160
250.160
260
260
260
300
310
310
310
310
320
320
330
330
350
360
360
370
380
380
400
400
400
400
410
420
430
444
446
450
464
466
466
470
470
470
500
504
506
506
660
720
730
740
742
750
750
750
750
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10 | 4139.301.635 | Gasket | |
| 12 | 0634.313.628 | O-ring | |
| 14 | 4139.301.613 | Insert | |
| 16 | 4139.301.614 | Insert | |
| 20 | 4139.347.308 | Connpart | |
| 50 | 0636.101.685 | Cap screw | |
| 50 | 0630.001.075 | Washer | |
| 56 | 0636.101.685 | Cap screw | |
| 56 | 0630.001.075 | Washer | |
| 62 | 0636.101.685 | Cap screw | |
| 62 | 0630.001.075 | Washer | |
| 68 | 0636.101.685 | Cap screw | |
| 68 | 0630.001.075 | Washer | |
| 74 | 0636.101.685 | Cap screw | |
| 74 | 0630.001.075 | Washer | |
| 80 | 0636.101.685 | Cap screw | |
| 80 | 0630.001.075 | Washer | |
| 86 | 0636.101.685 | Cap screw | |
| 86 | 0630.001.075 | Washer | |
| 100 | 0501.326.079 | Screw plug | |
| 120 | 0501.326.080 | Screw plug | |
| 124 | 0501.322.530 | Temperature sensor | |
| 124 | 0634.801.151 | Sealing ring | |
| 220 | 0634.313.057 | O-ring | |
| 250 | 0501.210.976 | Accumulator | |
| 250.110 | 0501.316.662 | Cover | |
| 250.120 | 0501.316.665 | Cover | |
| 250.130 | 0501.315.536 | Pipe | |
| 250.140 | 0501.210.277 | Piston | |
| 250.150 | 0634.313.267 | O-ring | |
| 250.160 | 0636.015.227 | Hexagon bolt | |
| 250.160 | 0630.001.048 | Washer | |
| 260 | 0636.101.663 | Cap screw | |
| 260 | 0630.001.075 | Washer | |
| 300 | 0634.316.159 | O-ring | |
| 310 | 0501.316.527 | Solenoid valve | |
| 320 | 0636.304.047 | Screw plug | |
| 320 | 0634.801.205 | Sealing ring | |
| 330 | 0636.010.375 | Hexagon bolt | |
| 330 | 0630.001.075 | Washer | |
| 350 | 0730.001.419 | Shim | |
| 350 | 0730.001.420 | Shim | |
| 350 | 0730.002.331 | Shim | |
| 350 | 0730.004.424 | Shim | |
| 350 | 0730.001.421 | Shim | |
| 350 | 0730.001.422 | Shim | |
| 350 | 0730.001.423 | Shim | |
| 360 | 4139.347.244 | Fixing plate | |
| 370 | 0730.003.290 | Washer | |
| 370 | 0730.003.287 | Washer | |
| 370 | 0730.003.286 | Washer | |
| 370 | 0730.003.127 | Washer | |
| 370 | 0730.003.126 | Washer | |
| 370 | 0730.003.125 | Washer | |
| 380 | BOLT+NUT | Bolt+nut | |
| 380 | 0636.015.257 | Hexagon bolt | |
| 380 | 0630.001.075 | Washer | |
| 380 | 0637.006.280 | Hexagon nut | |
| 400 | 0634.313.600 | O-ring | |
| 410 | 4139.347.489 | Pipe | |
| 420 | 4139.347.490 | Pipe | |
| 430 | 4139.347.284 | Gasket | |
| 444 | 4139.347.195 | Flange | |
| 446 | 0636.016.412 | Hexagon bolt | |
| 450 | 4139.347.363 | Connpart | |
| 464 | 4139.347.495 | Bracket | |
| 466 | 0636.101.680 | Cap screw | |
| 466 | 0630.001.075 | Washer | |
| 470 | 0636.010.375 | Hexagon bolt | |
| 470 | 0630.001.075 | Washer | |
| 500 | 0501.008.286 | Heat exchanger | |
| 504 | 4139.347.365 | Bracket | |
| 506 | 0636.016.403 | Hexagon bolt | |
| 506 | 0630.001.048 | Washer | |
| 660 | 4139.347.299 | Fixing plate | |
| 720 | 4139.347.198 | Fixing plate | |
| 730 | 0636.016.412 | Hexagon bolt | |
| 740 | 4139.347.301 | Bracket | |
| 742 | 0730.063.339 | Pipe | |
| 750 | 0636.010.374 | Hexagon bolt | |
| 750 | 0630.001.075 | Washer | |
| 750 | 0637.011.530 | Hexagon nut |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
