Каталог запасных частей к технике: King Long Автобус XMQ-6127J. GEARBOX
10
20
30
40
50
50
60
70
74
80
80.110
80.120
80.130
80.140
90
100
100.110
100.120
100.130
100.130
100.130
100.140
100.140
100.140
100.150
100.150
100.160
100.170
110
150
150.110
150.120
150.130
150.130
150.130
150.130
150.130
150.140
150.140
150.140
150.150
150.150
150.154
150.154
150.160
150.170
150.180
150.190
190
200
200
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10 | 4139.233.229 | Input shaft | |
| 20 | 0750.115.518 | Needle sleeve | |
| 30 | 0730.150.625 | Thrust washer | |
| 40 | 4139.233.126 | Quill shaft | |
| 50 | 0750.115.520 | Needle cage | |
| 60 | 0730.150.638 | Thrust washer | |
| 70 | 0735.320.782 | Needle cage | |
| 74 | 0730.150.630 | Thrust washer | |
| 80 | 4139.233.189 | Disc carrier | |
| 80.110 | 4139.333.019 | Disc carrier | |
| 80.120 | 4149.333.389 | Sun gear | |
| 80.130 | 0630.513.021 | Snap ring | |
| 80.140 | 0630.513.080 | Snap ring | |
| 90 | 0730.150.637 | Thrust washer | |
| 100 | 4139.233.207 | Planetary drive | |
| 100.110 | 4149.333.034 | Planet carrier | |
| 100.120 | 4139.333.088 | Bearing pin | |
| 100.130 | 0735.320.481 | Needle cage | |
| 100.130 | 0735.321.462 | Needle cage | |
| 100.140 | 4149.233.015 | Planet gear set | |
| 100.140 | 4139.233.315 | Planet gear set | |
| 100.150 | 0501.305.970 | Thrust plate | |
| 100.160 | 4139.333.894 | Ring gear | |
| 100.170 | 0730.503.079 | Retaining ring | |
| 110 | 0730.150.636 | Thrust washer | |
| 150 | 4149.233.004 | Planetary drive | |
| 150.110 | 4149.333.023 | Planet carrier | |
| 150.120 | 4139.333.864 | Bearing pin | |
| 150.122 | 0501.315.917 | Slotpin | |
| 150.130 | 0735.320.480 | Needle cage | |
| 150.130 | 0735.321.461 | Needle cage | |
| 150.140 | 4149.233.012 | Planet gear set | |
| 150.140 | 4139.233.314 | Planet gear set | |
| 150.150 | 0501.305.968 | Thrust plate | |
| 150.154 | 0501.305.969 | Thrust plate | |
| 150.160 | 4139.333.003 | Ring gear | |
| 150.170 | 0730.503.089 | Retaining ring | |
| 150.180 | 4139.333.668 | Ring gear | |
| 150.190 | 0730.503.079 | Retaining ring | |
| 190 | 0730.150.639 | Thrust washer | |
| 200 | 4139.333.774 | Sun gear |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
