Каталог запасных частей к технике: King Long Автобус XMQ-6127J. ENGINE CONTROL MODULE
1
2
3
4
5
6
7
7
8
9
10
11
12
13
14
15
16
17
18
18
18
19
20
21
22
23
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 3900629 | Screw, Hex Flange Head Cap | |
| 2 | 3900630 | Screw, Hex Flange Head Cap | |
| 3 | 3900633 | Screw, Hex Flange Head Cap | |
| 4 | 3901445 | Screw, Hex Flange Head Cap | |
| 5 | 3913638 | Screw, Hex Flange Head Cap | |
| 6 | 3920854 | Screw, Captive Washer Cap | |
| 7 | 3944816 | Screw, Hex Flange Head Cap | |
| 8 | 3955219 | Isolator, Vibration | |
| 9 | 3955220 | Isolator, Vibration | |
| 10 | 3957849 | Screw, Socket Head Cap | |
| 11 | 3977357 | Wire | |
| 12 | 4076493 | Sensor, Pressure | |
| 12 | 4076930 | Switch, Pressure | |
| 13 | 4076931 | Switch, Pressure | |
| 14 | 4921574 | O-ring seal | |
| 15 | 4903482 | O-ring seal | |
| 16 | 4921322 | Sensor, Prs Temperature | |
| 16 | 4921323 | Sensor, Prs Temperature | |
| 17 | 4921684 | Sensor, Position | |
| 17 | 4921685 | Sensor, Position | |
| 17 | 4921686 | Sensor, Position | |
| 18 | 4928599 | O-ring seal | |
| 18 | 4928599 | O-ring seal | |
| 19 | 4921687 | Sensor, Position | |
| 20 | 4933570 | Cooler, Electronic Control | |
| 21 | 4954905 | Sensor, Temperature | |
| 22 | 4995444 | Module, Electronic Control | |
| 23 | 4894985 | Nameplate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
