Каталог запасных частей к технике: King Long Автобус XMQ-6127J. COUPLING
10
20
30
40
46
50
60
64
70
80
90
100
110
120
130
140
150
160
160
160
160
170
170
180
180
180
190
210
230
250
260
270
270
270
270
280
280
300
310
320
330
400
400
400
400
400
410
410
420
430
440
450
454
460
470
480
490
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10 | 4139.333.755 | Turbine shaft | |
| 20 | 0730.062.250 | Pipe | |
| 30 | 0750.115.519 | Needle sleeve | |
| 40 | 4149.333.020 | Hub | |
| 46 | 0730.112.942 | Washer | |
| 50 | 0630.531.047 | Retaining ring | |
| 60 | 0635.490.065 | Needle roller | |
| 64 | 0631.329.095 | Slotpin | |
| 70 | 4149.270.010 | Clutch carrier | |
| 80 | 0501.320.375 | Sealing ring | |
| 90 | 0501.320.376 | Sealing ring | |
| 100 | 4149.370.060 | Piston | |
| 110 | 0732.000.078 | Cup spring | |
| 120 | 4139.333.040 | Fixing plate | |
| 130 | 0630.513.028 | Snap ring | |
| 140 | 0732.000.169 | Cup spring | |
| 150 | 4139.333.631 | Fixing plate | |
| 160 | 4139.333.765 | Iclutch disc | |
| 160 | 4139.333.036 | Iclutch disc | |
| 170 | 4139.270.035 | Oclutch disc | |
| 180 | 4139.333.694 | End shim | |
| 180 | 4149.333.033 | End shim | |
| 190 | 6600.300.048 | Split ring | |
| 210 | 0501.320.370 | Sealing ring | |
| 230 | 4149.370.035 | Piston | |
| 250 | 0501.320.371 | Sealing ring | |
| 260 | 4139.333.373 | Disc | |
| 270 | 4139.333.759 | Oclutch disc | |
| 270 | 4139.333.172 | Oclutch disc | |
| 280 | 4139.270.036 | Iclutch disc | |
| 300 | 4149.370.028 | End shim | |
| 310 | 4139.333.197 | Pin | |
| 320 | 0731.201.560 | Pin | |
| 330 | 0732.041.421 | Comprspring | |
| 400 | 4149.370.005 | Oclutch disc | |
| 400 | 4149.370.001 | Oclutch disc | |
| 400 | 4149.370.004 | Oclutch disc | |
| 410 | 4139.270.036 | Iclutch disc | |
| 420 | 4139.333.437 | Disc | |
| 430 | 4139.333.197 | Pin | |
| 440 | 0501.320.369 | Sealing ring | |
| 450 | 4149.270.007 | Piston | |
| 454 | 4139.370.016 | Ring | |
| 460 | 0730.513.120 | Retaining ring | |
| 470 | 0501.320.377 | Sealing ring | |
| 480 | 0634.349.521 | O-ring | |
| 490 | 4149.370.002 | Pot |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
