Каталог запасных частей к технике: King Long Автобус XMQ-6127. Rear axle(Air suspension)
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23a
23b
24
25
26
27
28
29
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 24N-01068 | Air breather | |
| 2 | 24N-01065 | Plug, oil level hole | |
| 3 | 24N-01066 | Sealing washer | |
| 4 | 2401NS54-010 | Rear axle housing assy | |
| 5 | Gasket | Gasket coating position | |
| 6 | 24N-01063/Q341B14 | Bolt | |
| 7 | Q40514 | Heavy-duty spring washer | |
| 8 | 24N-01073 | Oil drain plug | |
| 9 | 4402090263 | Rear brake back plate | |
| 10 | Q151B1635-0H1 | Bolt | |
| 11 | 31N-04075 | Rear oil seal collar | |
| 12 | 31N-04080 | Rear hub oil seal assy | |
| 13 | 24N-01076 | Rear hub adjusting nut | |
| 14 | 24N-01081 | Lock washer | |
| 15 | Q2140616 | Screw | |
| Q40306 | Q40306 | Gasket 6 | |
| 16 | 24ABS-00011 | ABS rear gear ring | |
| 17 | 35XZB-02075 | Rear brake drum | |
| 18 | 31N-04020 | Rear hub inner bearing assy | |
| 19 | 31CKD-04015-B | Rear hub | |
| 20 | 31N-04030 | Rear hub outer bearing assy | |
| 21 | Wheelrim | Wheel rim | |
| 22 | Tirenut | Tire nut | |
| 23a | 31CKD-04051 | Tyre bolt | |
| 23b | 31CKD-04052 | Tyre bolt | |
| 24 | 24ABS-00012B | ABS sensor bracket | |
| 25 | 35Z02-00030 | ABS sensor | |
| 3502ABS-076 | 3502ABS-076 | Plug, ABS wiring hole | |
| 26 | 24N-03064 | Gasket, half axle | |
| 27 | 24N-01090 | Oil seal, half axle | |
| 28 | 24N-03065 | Half axle | |
| 29 | 24N-03063 | Bolt, half axle | |
| 35DDS-02065 | 35DDS-02065 | Rear hub & brake drum assy |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
