Каталог запасных частей к технике: King Long Автобус XMQ-6127. Passenger door and
1
2
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19
20
21
22
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | XMQ6127-5403016-100 | Glass | |
| 2 | 6105310UJ | Bolt lock, passenger door | |
| 3 | WBM-MB-HA-002 | Balancing pole | |
| 4 | JT-J106-6127M | Rubber strip, passenger door | |
| 5 | XMQ6127-6101000 | Aluminium passenger door, front | |
| 6 | XMQ6127-6102110 | Inner protective Panel, front passenger door | |
| 7 | XMQ6112-6102212 | Overhaul cover, front door lock | |
| 8 | JT-B848 | Rubber strip, door inside seal panel | |
| 9 | JT-BB148 | Outer rubber strip, doorcase | |
| 10 | LD31-6063-1644 | Aluminium section | |
| 11 | JT-J105-6127 | Rubber strip, doorcase | |
| 12 | XMQ6112-6108106SL | Cover, door pump rotation arm column | |
| 13 | WBM-MB-MBZ-100 | Pneumatic outer-swing mechanism assembly | |
| 14 | WBM-MB-HA | Door pump | |
| 15 | PJ-10A-SHCA-CB40B75(12) | Cylinder, footboard | |
| 16 | 5113110L4 | pedal mechanism assy | |
| 17 | XMQ6112-5113202 | step spring , movable | |
| 18 | XMQ6111-5113602 | Rubber pedal, movable | |
| 19 | 3730530L4 | Controller, Doorlock | |
| 20 | WBM-MB-HA-001 | Magnet valve, door pump | |
| 21 | WBM-MB-HA-005 | Switch, journey | |
| 22 | DQ-STF-628 | Switch, emergency |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
