Left side window and skin
Каталог запасных частей к технике: King Long Автобус XMQ-6127. Left side window and skin
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
Golden Dragon
Hyundai
Ikarus
Karosa
King Long
Neoplan
Yutong
ZF
АМАЗ
Богдан
ЗИЛ
КАВЗ
Камский автозавод
ЛАЗ
ЛЗГМП
ЛиАЗ
Нефтекамский автозавод
ПАЗ
УралАЗ
Модель
Не выбрано
Автобус XMQ-6127 (2007)
Автобус XMQ-6127J (2010)
Автобус XMQ-6129Y (2010)
Автобус XMQ-6129Y5 (2015)
Автобус XMQ-6800Y (2010)
Схема
>
Не выбрано
Assembly, cylinder
Timing gear housing
Assembly, cylinder head
Assembly, piston & connecting rod
Assembly, crankshaft&flywheel
Assembly, camshaft
Assembly, valve tappet
Air intake pipe
Air exhaust pipe
Assembly, oil sump
Oil strainer assy
Assembly, oil pump
Assembly, oil filter
Assembly, oil cooler
Assembly, fuel pipeline
Assembly, fuel filter
Assembly, fuel injection pump
Assembly, fuel injector
Assembly, supercharger
Water drain faucet
Assembly, warm air&water intake valve
Assembly, water pump
Clutch parts
Assembly, air compressor
Assembly, starter
Engine suspension
Air intake system
Air exhaust system
Cooling system
Cooling water pipe
Intercooler
Fuel tank and supply pipeline
Accelerator cable and idle speed adjustment
Belt
Clutch control mechanism
Clutch assy
Transmission control mechanism
Output flange (with retarder)
Countershaft
Input shaft and countershaft end cover
Transmission housing and reverse shaft
Input shaft
Output shaft and gear
Selector shaft
Shift fork
Front air suspension
Rear air suspension
Propeller shaft
Front axle (Air spring) 30NS01R-00005
Steering tie rod
Front arrester
Rear axle(Air suspension)
Rear arrester 3502X02-020A
Final reduction gear (I=4.10) Q1-2402S106F-010
Wheel
Steering system (1)
Steering system (2)
Brake control unit (1)
Brake control unit (2)
Retarder (Telma F 191)
Front wall
Right side window and skin
Left side window and skin
Left side bin gate assy
Right side bin gate assy
Rear wall
Passenger door and
Central door mounting
Inner trim (I)
Inner trim (II)
Inner trim (III)-luggage rack
Passenger seat guardrail layout and water fountainer
KE-1 Jiangsong passenger seat
Body accessory
External rearvew mirror
Wiper
Electrical equipment (I)- Lamp
Electrical equipment (II)
Instrument desk and electrical equipment
Central control box
Rocker switch and indicator lamp
Indicator, instrument and wiring harness
Air conditioner-Wiring harness sketch
Air conditioner-Condenser system
Air conditioner-Evaporator system
Air conditioner-Exterior pipeline link
Compressor mounting
1
2
3
4
5
6
7
8
8
8
8
9
10
11
Позиция на иллюстрации
Заводской номер детали
Название детали
1
XMQ6127-5502102
Skin
2
XMQ6127-5503020-002
Laminated glass, sliding window
3
LD31-6063-4524
Aluminum section
4
XMQ6127-5503015-101
Laminated glass
5
LD31-6063-4524
Aluminum section
6
XMQ6127-5403011-003
Laminated glass
7
XMQ6127-5403012-003
Laminated glass
8
XMQ6127-5403013
Laminated glass
9
XMQ6127-5503018-001
Laminated glass
10
XMQ6127A-5402302
Grill
11
XMQ6127-5402999
Rolling skin
