Каталог запасных частей к технике: King Long Автобус XMQ-6127. Cooling system
1
2
3
4
4
4
5
5
6
7
8
9
10
11
11
12
13
13
14
14
15
16
17
18
19
20
21
22
23
24
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | XMQ6112-1308002 | Idle pulley assy | |
| 2 | ZC-206 | Bearing, idle pulley | |
| 3 | XMQ6111-1308003(12) | Axle, idle pulley | |
| 4 | XMQ6112-1308001(12) | Adjusting rod assy | |
| 5 | ZC-206(12) | Bearing, fan pulley | |
| 6 | XMQ6111-1308004(12) | Axle, fan pulley | |
| 7 | XMQ6111-1308005(12) | Connecting flange, fan | |
| 8 | XMQ6111-1308000 | Fan blade | |
| 9 | XMQ6702B-1302102 | Rubber ring, strut seat, water tank | |
| 10 | XMQ6115-1302100-DA | Left strut, water tank | |
| 11 | 84C-00012 | Installation cushion, water tank | |
| 12 | XMQ6115F-1302010 | Left bracket, water tank | |
| 13 | 84C-00011 | Installation cushion, water tank | |
| 14 | XMQ6111-1308020 | Bracket, strut, water tank | |
| 15 | XMQ6122C-1309001 | Fan shroud | |
| 16 | XMQ6122C-1301010 | Water tank | |
| 17 | XMQ6115F-1302052 | Rear bracket, water tank | |
| 18 | XMQ6115F-1302020 | Right strut, water tank | |
| 19 | XMQ6115-1302123 | Right strut, water tank | |
| 20 | XMQ6115F-1302051 | Fixing bracket, water tank | |
| 21 | XMQ6702B-1302103 | Rubber ring, strut seat, water tank | |
| 22 | XMQ6127F-1302010 | Bracket assy, fan | |
| 23 | XMQ6115-1302123 | Right strut, water tank | |
| 24 | XMQ6112-1308003 | Fan pulley assy |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
