Каталог запасных частей к технике: King Long Автобус XMQ-6127. Brake control unit (2)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
21
22
23
24
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | XMQ6113G-3500017 | Trio pedal assembly | |
| 2 | XMQ6112-3506022 | Free flow coupling | |
| 3 | 6CTAR13-052 | Free flow coupling | |
| 4 | 6CTAR13-051 | Free flow coupling | |
| 5 | 35C03-11010 | Air dryer assembly | |
| 6 | XMQ6115J5-3506051 | Bracket, air dryer | |
| 7 | XMQ6112-3506022 | Free flow coupling | |
| 8 | XMQ6119-3521622 | Nut | |
| 9 | XMQ6112-3506010 | Expansion tank | |
| 10 | XMQ6119-3521622 | Nut | |
| 11 | XMQ6112-3506021 | Free flow coupling | |
| 12 | 3513D-040 | Water drain valve assy, expansion tank | |
| 13 | XMQ6892-3513051 | Bracket, expansion tank | |
| 14 | XMQ6111-3506020 | Regenerative tank assembly | |
| 15 | XMQ6119-3521612 | Nut | |
| 16 | XMQ6119-3521742 | Free flow coupling | |
| 17 | 3513D-040 | Water drain valve assy, expansion tank | |
| 18 | DQ-CGQ-VD-QG201 | Sensor, air pressure alarm | |
| 19 | 35R13-06020 | Angle coupling | |
| 20 | 3513D-040 | Water drain valve assy, expansion tank | |
| 21 | XMQ6112-3513020 | Upper bracket, air reservoir | |
| 22 | 3513R13-010 | Air reservoir assy | |
| 23 | XMQ6119-3521786 | Angle coupling | |
| 24 | Q81412 | Connector |
