Каталог запасных частей к технике: King Long Автобус XMQ-6127. Assembly, oil pump
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | L3000-1011080 | Binder, gasket II | |
| 2 | L30YA-1011050 | Assembly, oil drain pipe | |
| 3 | Q150B0860TF2 | Bolt | |
| 4 | Q5280532 | Pin | |
| 5 | A30-1011028 | Plug, pressure limiting valve, oil pump | |
| 6 | A30-1011029 | Spring, pressure limiting valve, oil pump | |
| 7 | A30-1011031 | Retaining ring | |
| 8 | Q5210412 | Pin | |
| 9 | A30-1011022 | Driving gear, oil pump | |
| 10 | A30-1011025 | Driving gear shaft, oil pump | |
| 11 | L3000-1011024A | Cover, oil pump | |
| 12 | L3000-1011041 | Idle gear, oil pump | |
| 13 | L3000-1011023 | Gear, oil pump | |
| 14 | Q151C1250TF2 | Bolt | |
| 15 | L3000-1011032A | Anti-friction plate | |
| 16 | Q150B0820TF2 | Bolt | |
| 17 | A30-1011026 | Driven gear shaft, oil pump | |
| 18 | L3000-1011034A | Idle shaft, oil pump | |
| 19 | L3000-1011021B | Oil pump | |
| 20 | L3000-1011035 | Locating sleeve | |
| 21 | Q218B0825TF2 | Bolt | |
| 22 | Q40308 | Gasket 8 |
