Каталог запасных частей к технике: Golden Dragon XML6845CN-3150236. TOP COVER & SIDE PANEL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6845E02-5500100-FK35 | Side wall | |
| 2 | 6845E02-5500200-DW92 | Covered pillar | |
| 3 | CYC-002 | Safety hammer | |
| 4 | 6720-360L | End cover, sliding channel, left curtain | |
| 5 | 5704-533-JD1 | Strip, sliding channel, curtain | |
| 6 | 6720-360R | End cover, sliding channel, right curtain | |
| 7 | LXC1660-6M | Aluminum profile | |
| 8 | 6845E02-5500110-9S26 | Door trim panel | |
| 9 | 6895E01-6100010-00ZS | Cover, passenger door shaft | |
| 10 | 6890E03-5709911 | Door pump cover, middle door | |
| 11 | 5405-111-Z4P | Access door | |
| 12 | FSG-0001-JT | Armrest profile trim strip | |
| 13 | FN08-6845 | Striplights | |
| 14 | YC-H516A | Audio speaker | |
| 15 | WZ-516A | Cover, audio speaker | |
| 16 | DS/910A-Y-H-A1 | Skylight assy | |
| 17 | ST1787-1600 | Bottom plate, molding strip | |
| 18 | ST1786-1600 | Cover plate, molding strip | |
| 19 | L595 | Molding strip, mid roof | |
| 20 | 6845E01-5709300-9S26 | Trim panel, inner roof | |
| 21 | 336.H3DKX-02C | Camera | |
| 22 | 82G13-01010-A | Round interior rearview mirror | |
| 23 | STYT11-980 | Bottom plate, front/rear molding strip | |
| 24 | STYT12-980 | Molding strip cover, front/rear roof | |
| 25 | 6845E01-5709200-9S26 | Trims, front/rear roof | |
| 26 | 6845E02-5500300-DW92 | Corner piller, rear | |
| 27 | 6845E01-5500112-BY88 | Pipe cover | |
| 28 | XML5003201JA1 | Down covered pillar left end cover | |
| 29 | XML5003202JA1 | Down covered pillar right end cover | |
| 30 | LXC2630B-6M | Profile | |
| 31 | 6125E01-5500230-120F | Wire cover | |
| 32 | 6845E02-5405010 | Covered pillar, column B | |
| 33 | G-6-PT | Grey G-6 Leather | |
| 34 | 6925E01-5709100-9S26 | Trims | |
| 35 | LXC1621-5.65M | 1621profile terminal | |
| 36 | LXC1621-5M | 1621profile terminal | |
| 37 | LXC1621-6M-DT | 1621 profile terminal | |
| 38 | 6890E03-5709912 | Door pump cover, front door | |
| 39 | JF-102N | Emergency valve | |
| 40 | 5405-010-WA0 | Wire box, side guideboard |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
