Каталог запасных частей к технике: Golden Dragon XML6845CN-3150236. STEERING SYSTEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6895E01-3402205A | Steering bracket assy | |
| 2 | Q40112 | Plane washer | |
| 3 | Q40312 | Spring washer | |
| 4 | Q340B12 | Nut | |
| 5 | Q150B1240 | Bolt | |
| 6 | 6845Y04-3402016-A449 | Mounting bracket, column | |
| 7 | 3402-303-B5F-B1 | Adjusting bracket | |
| 8 | Q150B1035 | Bolt | |
| 9 | Q40110 | Plane washer | |
| 10 | Q40310 | Spring washer | |
| 11 | Q340B10 | Nut | |
| 12 | 6845Y04-3402100 | Steering column assy | |
| 13 | 6845Y04-3402024-A449 | Front floor assy | |
| 14 | 3401F2-010 | Steering gear assembly | |
| 15 | 6845Y04-3401011-B | Pitman arm | |
| 16 | Q151B2080TF2 | Bolt | |
| 17 | Q40120T16F9 | Plane washer | |
| 18 | Q341B20T13F2 | Nut | |
| 19 | 6845E06-3401030-AA21 | Drag-link assembly | |
| 20 | 3774-200-B5G | Combination switch cover | |
| 21 | 34E02-02010 | Bus steering wheel | |
| 22 | 6155Y01-3774100 | Combination switch assembly | |
| 23 | 6937A16-3704100 | Ignition switch assy | |
| 24 | 3402-301-B5F | Dust boot, rubber | |
| 25 | Q2714832 | Self-tapping screw | |
| 26 | Q40106 | Plane washer | |
| 27 | Q40306 | Spring washer | |
| 28 | 3402-302-B5F | Compression ring, dust boot |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
