Каталог запасных частей к технике: Golden Dragon XML6845CN-3150236. COOLING SYSTEM

Тип техники

Марка

Модель

Схема

Позиция на иллюстрации	Заводской номер детали	Название детали
1	6103A02-1119010	Intercooler assembly
2	XMLA2-1301010	Radiator assembly
3	6123W01-1309091	Cowl kit
4	F620-125-146-10C	Fan assembly
5	XML1313-3-165-A	Three-speed electromagnetic clutch device
6	AV22X1105	Belt
7	6100A1-1025010	Intermediate pulley assembly, adjusting lever
8	AV22X1715	Belt
9	6845E18-1302010-EZ54	Cross beam fitting, front, radiator
10	6845E18-1302020-DT14	Bracket component, radiator
11	6857A45-1302040	Brcket
12	13R16-02020B	Mounting cushion, radiator
13	6845E18-1302030-DT14	Front cross beam, mounting, radiator
14	6100A1-1313002	Strut support
15	Q7471040	Ball joint
16	XML1313001C9F0	Strut, water tank
17	Q7461040	Ball joint
18	6125G02-1302901	Fixing plate, radiator
19	6115E11-1303011	Connector, rubber
20	6837A31-1303029	Bracket, fixing water pipe
21	6100A1-1303312	U-bolt
22	6845Y10-1303022-FK35	Water intake pipe, engine
23	SGY5512-150-5010-X	Rubber hose
24	6102E25-1303013	Connector, rubber
25	6845Y10-1303012-FK35	Steel pipe, water outlet, engine
26	6113A03-1302901	Fixing plate, radiator
27	6123W01-1301602	Sturt, water tank
28	6937A32-1311010-JS	Expension water tank assembly
29	6122K01-3820810	Electric alarm switch, water level, water tank
30	SYYB-08	Vent pipe
31	TXBGT0-177	Clamp
32	6845E18-1311030-DU20	Bracket
33	6845E18-1311040-DU20	Bracket
34	XML8101007N1C0	Hot water pipe
