Каталог запасных частей к технике: Golden Dragon XML6139JR-3141082. XML-3900 TOOLS SUPPLIED WITH THE BUS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | QJD-16T | Jack | |
| 2 | S32 | Wrench, sleeve, wheel | |
| 3 | S22-4 | Wrench, sleeve, wheel | |
| 4 | DQRG-8 | Inflation hose | |
| 5 | GXQB | Lever | |
| 6 | SXQB | Lever | |
| 7 | HYQ-400 | Grease gun with hose | |
| 8 | JZQ | sharp nose pliers | |
| 9 | LS3900000-QYB | Tyre pressure gauge | |
| 10 | LYQ-8 | 8-Slip joint plier | |
| 11 | QMXBS | Wrench, tire valve | |
| 12 | SC-8 | Hand hummer | |
| 13 | SZXJ-6 | Hex screw spinning tool | |
| 14 | YZXJ-6 | Linear shape spinning tool | |
| 15 | HDBS-12 | 12 spanner wrench | |
| 16 | HDBS-6 | 8 spanner wrench | |
| 17 | BT680X22 | Spare tyre regulator | |
| 18 | LQQBS | Fuel filter wrench | |
| 19 | XML-3900 | Universal tools supplied with the bus |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
