Каталог запасных частей к технике: Golden Dragon XML6139JR-3141082. TOP COVER&SIDE PANEL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6139X13-5500420 | Side wall, right | |
| 2 | 6127K71-5500211-60 | Cover, pillar | |
| 3 | PT041-6139X13-R | Cover, beam | |
| 4 | WY004 | Safety hammer | |
| 5 | 509010011 | Curtain buckle double | |
| 6 | 6139X13-8205010 | Curtain | |
| 7 | LB102 | Lengthened air outlet, normally- open | |
| 8 | 2768JCT | Strip, luggage compartment | |
| 9 | SLB0015-2400W750 | ABS Plate | |
| 10 | DS/910B-Y-A1-WS | Safety skylight | |
| 11 | 6125K01KKT | Boynet strip, light | |
| 12 | 6139X13-5709210 | Compartment door, luggage rack | |
| 13 | 6129LBB | Horn, panel | |
| 14 | W-10 | Air outlet plate | |
| 15 | 6139X03-5709701 | Transient air duct, | |
| 16 | 6139X13-5709300 | Molding strip | |
| 17 | 336.H3DKY-02 | Camera | |
| 18 | ME-1813V-H | LCD | |
| 19 | 6139X13-5709200-D-2 | Air duct & luggage rack assy | |
| 20 | PT041-6139X13-L | Cover, beam | |
| 21 | 6139X13-5500410 | Side wall, left | |
| 22 | JF-102N | Emergency valve | |
| 23 | 6102K01-5500025-CF | Trim cover, emergency valve | |
| 24 | 6139X13-5500510 | Cover, middle door pillar | |
| 25 | PT041-DT-R | End cover, covered pillar | |
| 26 | 6122K02-5500120 | Cover, rear corner | |
| 27 | JSTL560-3500 | Strip | |
| 28 | L550 | Strip | |
| 29 | 6139X13-5709500 | Rear roof panel | |
| 30 | 6139X13-5500040 | Strip | |
| 31 | 6139X03-5500430 | Rear wall | |
| 32 | 6122K02-5500110 | Cover, rear corner | |
| 33 | PT041-DT-L | End cover, covered pillar | |
| 34 | 6122K02-5709410 | Luggage rack terminalleft | |
| 35 | XMD-W-02 | Air outlet | |
| 36 | 19706109 | Spot light | |
| 37 | 6139X13-8205020 | Curtain | |
| 38 | 6139X13-5500011 | Inner trim , driver window | |
| 39 | 6139X13-5500013 | Inner trim , driver window | |
| 40 | 6139X13-5500012 | Inner trim , driver window | |
| 41 | 7214N-X | Blower | |
| 42 | NLG62.5-FD | Pipe | |
| 43 | 6122K02-5709420 | Luggage rack terminalright | |
| 44 | 6139X13-5709100 | Roof assy, front | |
| 45 | 6139X13-5500023 | Inner trim , front door pillar | |
| 46 | 6139X13-5500021 | Inner trim , front door pillar | |
| 47 | 6139X03-5500022 | Inner trim , front door pillar |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
