Каталог запасных частей к технике: Golden Dragon XML6139JR-3141082. REAR PANEL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | W250X55 | Combined reflector, foglight, rear | |
| 2 | Z-HX778X280L | Combination light, rear , left | |
| 3 | 6139X03-5602100 | Protective covering, rear panel | |
| 4 | SK151X36 | Rear marker lamp | |
| 5 | 6108K01-5603100 | Rear windshield | |
| 6 | ZD950X35 | Brake light, high position | |
| 7 | Z-HX778X280R | Combination light, rear , right | |
| 8 | 6139X03-5604100 | Compartment door, rear | |
| 9 | 6127A06-4108100 | License plate light | |
| 10 | 6139X03-5602200 | Rear bumper | |
| 11 | 6100A1-3719100-A1 | Reversing buzzer | |
| 12 | FZBA0.4-C/GW | Nacelle automatic fire extinguishers | |
| 13 | QT737-00-A1 | Working lamp , engine compartment | |
| 14 | QD-3704071-XF | Bracket, rear starter box | |
| 15 | KW-HQD-F | Starter box, rear | |
| 16 | 1126-105C | Probe, engine compartment | |
| 17 | 00710-00201 | Fire extinguisher | |
| 18 | 6127A01-5604200 | Ball hinge | |
| 19 | QH625-380N220 | Air spring pole | |
| 20 | 6100A2-3746210 | Fixing bracket, door switch | |
| 21 | 6100A2-3746110 | Stroke switch, compartment door |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
