Каталог запасных частей к технике: Golden Dragon XML6139JR-3141082. PASSENGER DOOR INSTALLATION ASSEMBLY
1
1
1
2
3
3
4
4
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | XML6108101E1B0 | Trim cover, bracket, door | |
| 2 | 6128B01-6100200 | Door pump assy | |
| 3 | 6139X03-6100031-EK45 | Glass, front passenger door | |
| 4 | 6139X03-6100203 | Door pump , front | |
| 5 | 6100-6101023 | Bracket, stabilizer | |
| 6 | 6139X03-6700100 | Frame work, middle passenger door | |
| 7 | 6139X03-6700017 | Interior trim plate, middle door | |
| 8 | 6108K01-6700033 | Lower sealing strip, door | |
| 9 | 6108K01-6700021 | Aluminum profile, front pillar, middle door frame | |
| 10 | 6108K01-6700022 | Aluminum profile, rear pillar, middle door frame | |
| 11 | 6108K01-6700023 | Aluminum profile, upper beam, middle door frame | |
| 12 | 6108K01-6700031 | Rubber strip, middle door frame | |
| 13 | 6108K01-6700032 | Sealing rubber strip, middle door frame | |
| 14 | JTBB426 | Rubber strip | |
| 15 | JTBB427 | Rubber strip | |
| 16 | 6139X03-6100200-EK45 | Front passenger door panel assembly | |
| 17 | 6139X03-6100037-EK45 | Inner trim panel, passenger door | |
| 18 | 6127K71-6100038 | Sealing strip | |
| 19 | 6100A1-3746130HM-2 | Remote controller, door pump | |
| 20 | 6139X03-6100035-EK45 | Rubber strip | |
| 21 | 6139X03-6100036-EK45 | Rubber strip |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
