Каталог запасных частей к технике: Golden Dragon XML6127CNG-3141495. STEERING SYSTEM
1
2
3
4
5
6
6
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6127K12-3402012 | Front vertical plate | |
| 2 | 6127J21-3402042 | Mounting set, front floor | |
| 3 | 6127J01-3402041 | Front floor | |
| 4 | 6127K12-3402501 | Mounting beam, column | |
| 5 | 3402-303-B5F-B1 | Adjusting bracket | |
| 6 | 6126A14-3401056 | Friction washer | |
| 6 | 6126A14-3401057 | Friction washer | |
| 6 | 6126A14-3401058 | Friction washer | |
| 6 | 6126A14-3401059 | Friction washer | |
| 7 | 8098957133 | Steering gear assy. | |
| 8 | 6127K36-3401111 | Steering pitman arm | |
| 9 | 6127A14-3401055 | Friction washer | |
| 10 | 6125A20-3401210-KF | Drag-link assembly, front | |
| 11 | 6125A20-3401220-KF | Drag-link assembly, rear | |
| 12 | 6925Y01-3401060 | Middle rocker arm w/ bushing assembly | |
| 13 | Q701B45 | Goose-neck grease nozzle | |
| 14 | 6125Y06-3405071 | Middle rocker arm seat | |
| 15 | 6125Y06-3405073 | Middle rocker arm shaft | |
| 16 | 6125K01-3704100 | Ignation switch | |
| 17 | 6126A11-3774100 | Combination switch assembly | |
| 18 | SC05-03001 | Outer house, front | |
| 19 | SC05-03002 | Outer house, rear | |
| 20 | 11R105-3302005 | Fastening washer | |
| 21 | Q5005050 | Cotter pin | |
| 22 | 6108A05-3402301 | Dust boot, rubber | |
| 23 | 3402-302-B5F | Compression ring, dust boot | |
| 24 | Q2714832 | Self-tapping screw | |
| 25 | Q40306 | Spring washer | |
| 26 | Q40106 | Plane washer | |
| 27 | HFL1-6049-0000 | Steering wheel | |
| 28 | Q387B24-8 | Hex slotted thin nut | |
| 29 | 6121C07-3402300-ZS | Steering transmission device |
