REAR COVER
Каталог запасных частей к технике: Golden Dragon XML6127CNG-3141495. REAR COVER
zoom-in
zoom-out
enlarge
shrink
circle-right
circle-left
file-text2
info
cart
Тип техники
Не выбрано
Легковые автомобили
Грузовые автомобили и прицепы
Автобусы
Сельхозтехника
Спецтехника
Двигатели
Мототехника
Марка
Не выбрано
Golden Dragon
Hyundai
Ikarus
Karosa
King Long
Neoplan
Yutong
ZF
АМАЗ
Богдан
ЗИЛ
КАВЗ
Камский автозавод
ЛАЗ
ЛЗГМП
ЛиАЗ
Нефтекамский автозавод
ПАЗ
УралАЗ
Модель
Не выбрано
XML6105CN-7150227 (2015)
XML6125CN-3150244 (2015)
XML6127CNG-3141495 (2015)
XML6139JR-3141082 (2015)
XML6845CN-3150236 (2015)
Схема
>
Не выбрано
FRONT PANEL
6127X01-3741100-11 WIPER ASSEMBLY
SIDE PANEL
SIDE COMPARTMENT
BATTERY COMPARTMENT
PASSENGER DOOR INSTALLATION ASSEMBLY
REAR PANEL
DRIVER COMPARTMENT
ELECTRICAL APPARATUS, FRONT INSTRUMENTS PANEL
6999A01-3700100-RUS ELECTRIC BOX
TOP COVER & SIDE PANEL
ARMREST & SEAT
FLOOR COVERING & REPAIR HATCH
STEERING SYSTEM
STEERING OPERATION BOOSTING PIPELINE
11R105-3425120 STEERING OIL CAN
TRANSMISSION OPERATING MECHANISM
CLUTCH ASSEMBLY
CLUTCH OPERATION SYSTEM
SCHEMATIC DIAGRAM, BRAKE
ARRANGEMENT DIAGRAM, BRAKE
CONTROL AND FRONT BRAKE
AIR CYLINDER AND 4-WAY PROTECTIVE VALVE
AIR SUPPLY
REAR BRAKE AND PARKING BRAKE
ANTI-LOCK BRAKING SYSTEM (ABS)
FRONT AXLE ASSEMBLY
FRONT AXLE SYSTEM
WHEEL HUB WITH BRAKE DISC ASSEMBLY
REAR AXLE ASSEMBLY
REAR AXLE ASSY
FINAL DRIVE
WHEEL HUB WITH BRAKE DISC ASSEMBLY
FRONT SUSPENSION ASSEMBLY
JR-65F-12-40 FRONT AIR SUSPENSION ASSY
REAR SUSPENSION ASSEMBLY
JR-130R-12-29 REAR AIR SUSPENSION ASSY
AIR LEVELING
WHEEL INSTALLTION
DRIVE SHAFT INSTALLATION
6106G5-2201010 DRIVE SHAFT
GEARBOX ASSEMBLY
S6-160-158 GEARBOX ASSEMBLY
HOUSING, TRANSMISSION
HOUSING, CLUTCH
INPUT SHAFT, COUNTERSHAFT & REVERSE GEAR SHAFT ASSY
SHAFT, OUTPUT
REAR COVER
GEAR SHIFT MECHANISM
UPPER COVER & SHIFTING SHAFT
ENGINE& AROUND PARTS
AVI2120R3071A GENERATOR
ENGINE MOUNTING SYSTEM
REDUCER INSTALLATION
TB24-511074110-1 RETARDER DISASSEMBLY
TB24-511074110-2 ELECTRICAL APPARATUS
CHASSIS LUBRICATION SYSTEM
KFD-A CONTRAL LUBRICATION DEVICE
CHASSIS ACCESSORIES
GAS SYSTEM
THROTTLE CONTROL MECHANISM
AIR INTAKE SYSTEM
AH24196 AIR FILTER
EXHAUST SYSTEM
COOLING SYSTEM
6103A01-1311010-JS EXPENSION WATER TANK
6125Y10-1025010-JZ INTERMEDIATE PULLEY ASSY, ADJUSTING LEVER
AIR CONDITIONING SYSTEM
CONDENSER
EVAPORATOR
HEATING PIPELINE
T350 THE HEATER ASSEMBLY
CS-14H-30 DEFROSTER
NAME PLATE, COMPLETE SET
LOCK, COMPLETE SET
TOOLS SUPPLIED WITH THE BUS
XML-3900 TOOLS SUPPLIED WITH THE BUS
HARNESS, COMPLETE SET
55
60
65
66
71
72
73
74
76
77
100
115
116
Позиция на иллюстрации
Заводской номер детали
Название детали
55
1166308002
Speedometer cover
60
1268308003
Gasket
65
630361061
Sealing cap
66
734310113
Shaft seal
71
636015124
Bolt
72
Q150B1050
Hex bolt
73
630302091
Spring washer
74
Q1201045
Stud-Bolt
76
637006022
Nut
77
Q150B1080
Bolt
85
Q72310
Sealing washer
100
1096208004
Electronic mileage sensor
115
1269343006
Limit ring
116
635450115
Cylindrical roller bearing
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
