Каталог запасных частей к технике: Golden Dragon XML6127CNG-3141495. COOLING SYSTEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
16
17
18
18
19
19
20
21
21
22
23
24
25
26
27
28
29
30
31
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6129C31-1119010 | Intercooler assembly | |
| 2 | 6128J18-1301010 | Radiator assembly | |
| 3 | 6128J18-1309010 | Cowl kit | |
| 4 | F675W-125-146-9A | Fan assembly | |
| 5 | XML1313-3-178-B | Three-speed electromagnetic clutch fan | |
| 6 | RPF5445 | Belt | |
| 7 | 6125Y10-1025010-JZ | Intermediate pulley assembly, adjusting lever | |
| 8 | RPF5710 | Belt | |
| 9 | 6127X08-1302010 | Cross beam assembly, rear, radiator | |
| 10 | 6127K01-1311001 | Beam | |
| 11 | 13R16-02020 | Mounting cushion assembly, radiator | |
| 12 | 6128B37-1302050-B214 | Brcket | |
| 13 | 6128B37-1302070-B214 | Brcket | |
| 14 | 6128B37-1302040-B214 | Brcket | |
| 15 | 6100A1-1313002 | Strut support | |
| 16 | Q7461040 | Ball joint | |
| 17 | 6125S2-1313011 | Strut, water tank | |
| 18 | Q7471040 | Ball joint | |
| 19 | 6128J18-1302060 | Brcket | |
| 20 | 6126X01-1313001 | Strut, water tank | |
| 21 | 6145G01-1303011 | Water-outlet rubber hose | |
| 22 | 6122A86-1303022 | Steel pipe, water return | |
| 23 | 6125B04-1303019 | Brcket | |
| 24 | 6100A1-1303312 | U-bolt | |
| 25 | 6145A01-1303015 | Pipe connector | |
| 26 | 6125A01-1303011 | Water-outlet rubber hose | |
| 27 | 6128B36-1303012 | Steel pipe, outlet, thermostat | |
| 28 | 6122A38-3506106 | Rubber pipe | |
| 29 | 6103A01-1311010-JS | Expension water tank assembly | |
| 30 | 6122K01-3820810 | Electric alarm switch, water level, water tank | |
| 31 | SYYB-08 | Vent pipe |
